Advanced Linear Devices, Inc.
- Advanced Linear Devices, Inc., (ALD) develops and manufactures ultra-low-power, precision CMOS analog integrated circuits, related board level products and Energy Harvesting Modules and accessories incorporating the company's exclusive EPAD® technology. ALD's standard semiconductor products include a full complement of "best-of-breed" ultra-low-charge-injection low-voltage analog switches, dual-slope A/D converters and digital processors, precision voltage comparators, precision rail-to-rail CMOS operational amplifiers, and low-drift CMOS timers with high discharge output, as well as an extensive selection of enhancement, depletion, and zero-threshold mode EPAD matched small signal MOSFET arrays.
Part Number
Manufacturer
Description
Unit Price
In Stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : -
Part Status : Active
Amplifier Type : General Purpose
Number of Circuits : 2
Output Type : Push-Pull, Rail-to-Rail
Slew Rate : 2.8 V/µs
Gain Bandwidth Product : 1.5MHz
-3db Bandwidth : -
Current - Input Bias : 1pA
Voltage - Input Offset : 5mV
Current - Supply : 2mA
Current - Output / Channel : 8mA
Voltage - Supply, Single/Dual (±) : 4 V ~ 10 V, ±2 V ~ 5 V
Operating Temperature : 0°C ~ 70°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-PDIP
0
20 in stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : -
Part Status : Active
Amplifier Type : General Purpose
Number of Circuits : 2
Output Type : Rail-to-Rail
Slew Rate : 0.1 V/µs
Gain Bandwidth Product : 200kHz
-3db Bandwidth : -
Current - Input Bias : 0.1pA
Voltage - Input Offset : 2mV
Current - Supply : 50µA
Current - Output / Channel : 200µA
Voltage - Supply, Single/Dual (±) : 2 V ~ 10 V, ±1 V ~ 5 V
Operating Temperature : 0°C ~ 70°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-PDIP
0
100 in stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : -
Part Status : Active
Amplifier Type : General Purpose
Number of Circuits : 2
Output Type : Rail-to-Rail
Slew Rate : 0.1 V/µs
Gain Bandwidth Product : 200kHz
-3db Bandwidth : -
Current - Input Bias : 0.1pA
Voltage - Input Offset : 2mV
Current - Supply : 50µA
Current - Output / Channel : 200µA
Voltage - Supply, Single/Dual (±) : 2 V ~ 10 V, ±1 V ~ 5 V
Operating Temperature : 0°C ~ 70°C
Mounting Type : Surface Mount
Package / Case : 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package : 8-SOIC
0
50 in stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : -
Part Status : Active
Amplifier Type : General Purpose
Number of Circuits : 2
Output Type : Rail-to-Rail
Slew Rate : 0.1 V/µs
Gain Bandwidth Product : 200kHz
-3db Bandwidth : -
Current - Input Bias : 0.1pA
Voltage - Input Offset : 5mV
Current - Supply : 50µA
Current - Output / Channel : 200µA
Voltage - Supply, Single/Dual (±) : 2 V ~ 10 V, ±1 V ~ 5 V
Operating Temperature : 0°C ~ 70°C
Mounting Type : Surface Mount
Package / Case : 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package : 8-SOIC
0
100 in stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : -
Part Status : Active
Amplifier Type : General Purpose
Number of Circuits : 2
Output Type : Rail-to-Rail
Slew Rate : 1 V/µs
Gain Bandwidth Product : 700kHz
-3db Bandwidth : -
Current - Input Bias : 0.01pA
Voltage - Input Offset : 250µV
Current - Supply : 200µA
Current - Output / Channel : 1mA
Voltage - Supply, Single/Dual (±) : 2 V ~ 10 V, ±1 V ~ 5 V
Operating Temperature : 0°C ~ 70°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-PDIP
0
5 in stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : -
Part Status : Active
Amplifier Type : General Purpose
Number of Circuits : 2
Output Type : Rail-to-Rail
Slew Rate : 1 V/µs
Gain Bandwidth Product : 700kHz
-3db Bandwidth : -
Current - Input Bias : 0.01pA
Voltage - Input Offset : 250µV
Current - Supply : 200µA
Current - Output / Channel : 1mA
Voltage - Supply, Single/Dual (±) : 2 V ~ 10 V, ±1 V ~ 5 V
Operating Temperature : 0°C ~ 70°C
Mounting Type : Surface Mount
Package / Case : 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package : 8-SOIC
0
150 in stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : -
Part Status : Active
Amplifier Type : General Purpose
Number of Circuits : 2
Output Type : Rail-to-Rail
Slew Rate : 1 V/µs
Gain Bandwidth Product : 1MHz
-3db Bandwidth : -
Current - Input Bias : 0.01pA
Voltage - Input Offset : 500µV
Current - Supply : 200µA
Current - Output / Channel : 1mA
Voltage - Supply, Single/Dual (±) : 2 V ~ 12.6 V, ±1 V ~ 6.3 V
Operating Temperature : 0°C ~ 70°C
Mounting Type : Surface Mount
Package / Case : 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package : 8-SOIC
0
810 in stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : EPAD®, Zero Threshold™
Part Status : Active
FET Type : 4 P-Channel, Matched Pair
FET Feature : Standard
Drain to Source Voltage (Vdss) : 8V
Current - Continuous Drain (Id) @ 25°C : -
Rds On (Max) @ Id, Vgs : -
Vgs(th) (Max) @ Id : 20mV @ 1µA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 2.5pF @ 5V
Power - Max : 500mW
Operating Temperature : 0°C ~ 70°C
Mounting Type : Through Hole
Package / Case : 16-DIP (0.300", 7.62mm)
Supplier Device Package : 16-PDIP
0
51 in stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : EPAD®, Zero Threshold™
Part Status : Active
FET Type : 4 P-Channel, Matched Pair
FET Feature : Standard
Drain to Source Voltage (Vdss) : 8V
Current - Continuous Drain (Id) @ 25°C : -
Rds On (Max) @ Id, Vgs : -
Vgs(th) (Max) @ Id : 780mV @ 1µA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 2.5pF @ 5V
Power - Max : 500mW
Operating Temperature : 0°C ~ 70°C
Mounting Type : Surface Mount
Package / Case : 16-SOIC (0.154", 3.90mm Width)
Supplier Device Package : 16-SOIC
0
90 in stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : -
Part Status : Active
Switch Circuit : SPST - NC
Multiplexer/Demultiplexer Circuit : 1:1
Number of Circuits : 4
On-State Resistance (Max) : 135 Ohm
Channel-to-Channel Matching (δRon) : 2.7 Ohm
Voltage - Supply, Single (V+) : 3 V ~ 12 V
Voltage - Supply, Dual (V±) : ±1.5 V ~ 6 V
Switch Time (Ton, Toff) (Max) : 130ns, 130ns
-3db Bandwidth : -
Charge Injection : 0.2pC
Channel Capacitance (CS(off), CD(off)) : 3pF, 3pF
Current - Leakage (IS(off)) (Max) : 100pA
Crosstalk : -90dB @ 100kHz
Operating Temperature : -40°C ~ 85°C (TA)
Package / Case : 16-DIP (0.300", 7.62mm)
Supplier Device Package : 16-PDIP
0
29 in stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : -
Part Status : Active
Switch Circuit : SPST - NC
Multiplexer/Demultiplexer Circuit : 1:1
Number of Circuits : 4
On-State Resistance (Max) : 135 Ohm
Channel-to-Channel Matching (δRon) : 2.7 Ohm
Voltage - Supply, Single (V+) : 3 V ~ 12 V
Voltage - Supply, Dual (V±) : ±1.5 V ~ 6 V
Switch Time (Ton, Toff) (Max) : 130ns, 130ns
-3db Bandwidth : -
Charge Injection : 0.2pC
Channel Capacitance (CS(off), CD(off)) : 3pF, 3pF
Current - Leakage (IS(off)) (Max) : 100pA
Crosstalk : -90dB @ 100kHz
Operating Temperature : -40°C ~ 85°C (TA)
Package / Case : 16-SOIC (0.154", 3.90mm Width)
Supplier Device Package : 16-SOIC
0
31 in stock
Advanced Linear Devices, Inc.
Manufacturer : Advanced Linear Devices Inc.
Packaging : Tube
Series : -
Part Status : Active
Switch Circuit : SPST - NO/NC
Multiplexer/Demultiplexer Circuit : 1:1
Number of Circuits : 4
On-State Resistance (Max) : 135 Ohm
Channel-to-Channel Matching (δRon) : 2.7 Ohm
Voltage - Supply, Single (V+) : 3 V ~ 12 V
Voltage - Supply, Dual (V±) : ±1.5 V ~ 6 V
Switch Time (Ton, Toff) (Max) : 130ns, 130ns
-3db Bandwidth : -
Charge Injection : 0.2pC
Channel Capacitance (CS(off), CD(off)) : 3pF, 3pF
Current - Leakage (IS(off)) (Max) : 100pA
Crosstalk : -90dB @ 100kHz
Operating Temperature : -40°C ~ 85°C (TA)
Package / Case : 16-DIP (0.300", 7.62mm)
Supplier Device Package : 16-PDIP
0
100 in stock
