Delta Electronics
- Delta Group is the world's largest provider of switching power supplies and brushless fans, as well as a major source for power management solutions, components, visual displays, industrial automation, networking products, and renewable energy solutions. Established in 1971, Delta Group has sales offices worldwide and manufacturing plants in Taiwan, Thailand, China, Mexico and Europe. As a global leader in power electronics, Delta's mission is "To provide innovative, clean and efficient energy solutions for a better tomorrow." Delta is committed to environmental protection and has implemented green, lead-free production and recycling and waste management programs for many years.
Part Number
Manufacturer
Description
Unit Price
In Stock
Delta Electronics
Manufacturer : Delta Electronics
Series : TDV
Part Status : Active
Filter Type : Three Phase (Delta)
Configuration : Single Stage
Voltage - Rated DC : -
Voltage - Rated AC : 480V
Voltage - Rated AC (Phase to Ground/Neutral) : -
Voltage - Rated AC (Phase to Phase) : -
Current : 7A
Frequency - Operating : 50/60Hz
Applications : General Purpose
Approvals : cURus, ENEC, SEMKO
Operating Temperature : -25°C ~ 100°C
Mounting Type : Chassis Mount
Termination Style : Terminal Block
Inductance : 2.52mH
0
27 in stock
Delta Electronics
Manufacturer : Delta Electronics
Packaging : Bulk
Series : KEN
Part Status : Obsolete
Connector Style : IEC 320-C14
Connector Type : Receptacle, Male Blades
Current - IEC : 8A
Voltage - IEC : 115/250VAC
Current - UL : -
Voltage - UL : -
Filter Type : Filtered (EMI, RFI) - Commercial, Medical
Fuse : No
Number of Positions : 3
Mounting Type : Panel Mount, Snap-In
Termination : Quick Connect
Switch Features : -
Features : Mounting Clip
Fuse Holder, Drawer : -
Panel Cutout Dimensions : Rectangular - 28.45mm x 21.90mm
Panel Thickness : 0.032" ~ 0.063" (0.81mm ~ 1.60mm)
Material Flammability Rating : -
Ingress Protection : -
Approvals : CSA, UL, VDE
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Packaging : Bulk
Series : KEN
Part Status : Obsolete
Connector Style : IEC 320-C14
Connector Type : Receptacle, Male Blades
Current - IEC : 8A
Voltage - IEC : 115/250VAC
Current - UL : -
Voltage - UL : -
Filter Type : Filtered (EMI, RFI) - Commercial, Medical
Fuse : No
Number of Positions : 3
Mounting Type : Panel Mount, Snap-In
Termination : Quick Connect
Switch Features : -
Features : Bleed Resistor, Mounting Clip
Fuse Holder, Drawer : -
Panel Cutout Dimensions : Rectangular - 28.45mm x 21.90mm
Panel Thickness : 0.032" ~ 0.063" (0.81mm ~ 1.60mm)
Material Flammability Rating : -
Ingress Protection : -
Approvals : CSA, UL, VDE
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : TDT
Part Status : Active
Filter Type : Three Phase (Delta)
Configuration : Single Stage
Voltage - Rated DC : -
Voltage - Rated AC : 480V
Voltage - Rated AC (Phase to Ground/Neutral) : -
Voltage - Rated AC (Phase to Phase) : -
Current : -
Frequency - Operating : 50/60Hz
Applications : General Purpose
Approvals : -
Operating Temperature : -
Mounting Type : Chassis Mount
Termination Style : Terminal Block
Inductance : 7.6mH
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : TYT
Part Status : Active
Filter Type : Three Phase (Wye)
Configuration : Single Stage
Voltage - Rated DC : -
Voltage - Rated AC : 520V
Voltage - Rated AC (Phase to Ground/Neutral) : -
Voltage - Rated AC (Phase to Phase) : -
Current : -
Frequency - Operating : 50/60Hz
Applications : General Purpose
Approvals : UR
Operating Temperature : -
Mounting Type : Chassis Mount
Termination Style : Terminal Block
Inductance : 2.4mH
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : TYT
Part Status : Active
Filter Type : Three Phase (Wye)
Configuration : Two Stage
Voltage - Rated DC : -
Voltage - Rated AC : 520V
Voltage - Rated AC (Phase to Ground/Neutral) : -
Voltage - Rated AC (Phase to Phase) : -
Current : -
Frequency - Operating : 50/60Hz
Applications : General Purpose
Approvals : UR
Operating Temperature : -
Mounting Type : Chassis Mount
Termination Style : Terminal Block
Inductance : L1 - 2.4mH, L2 - 7µH
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : TD
Part Status : Active
Filter Type : Three Phase (Delta)
Configuration : Two Stage
Voltage - Rated DC : -
Voltage - Rated AC : 440V
Voltage - Rated AC (Phase to Ground/Neutral) : -
Voltage - Rated AC (Phase to Phase) : -
Current : -
Frequency - Operating : 50/60Hz
Applications : General Purpose
Approvals : -
Operating Temperature : -
Mounting Type : Chassis Mount
Termination Style : Threaded Post (M6)
Inductance : -
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : TDV
Part Status : Active
Filter Type : Three Phase (Delta)
Configuration : Single Stage
Voltage - Rated DC : -
Voltage - Rated AC : 480V
Voltage - Rated AC (Phase to Ground/Neutral) : -
Voltage - Rated AC (Phase to Phase) : -
Current : 100A
Frequency - Operating : 50/60Hz
Applications : General Purpose
Approvals : cURus, ENEC, SEMKO
Operating Temperature : -25°C ~ 100°C
Mounting Type : Chassis Mount
Termination Style : Terminal Block
Inductance : 300µH
0
6 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : TDV
Part Status : Active
Filter Type : Three Phase (Delta)
Configuration : Two Stage
Voltage - Rated DC : -
Voltage - Rated AC : 480V
Voltage - Rated AC (Phase to Ground/Neutral) : -
Voltage - Rated AC (Phase to Phase) : -
Current : 100A
Frequency - Operating : 50/60Hz
Applications : General Purpose
Approvals : cURus, ENEC, SEMKO
Operating Temperature : -25°C ~ 100°C
Mounting Type : Chassis Mount
Termination Style : Terminal Block
Inductance : L1 - 900µH, L2 - 8µH
0
1 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : TYS
Part Status : Active
Filter Type : Three Phase (Wye)
Configuration : Single Stage
Voltage - Rated DC : -
Voltage - Rated AC : 440V
Voltage - Rated AC (Phase to Ground/Neutral) : -
Voltage - Rated AC (Phase to Phase) : -
Current : -
Frequency - Operating : 50/60Hz
Applications : General Purpose
Approvals : CSA, ENEC, UL
Operating Temperature : -
Mounting Type : Chassis Mount
Termination Style : Threaded Post (1/4-20)
Inductance : -
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : TYT
Part Status : Active
Filter Type : Three Phase (Wye)
Configuration : Single Stage
Voltage - Rated DC : -
Voltage - Rated AC : 480V
Voltage - Rated AC (Phase to Ground/Neutral) : -
Voltage - Rated AC (Phase to Phase) : -
Current : -
Frequency - Operating : 50/60Hz
Applications : General Purpose
Approvals : -
Operating Temperature : -
Mounting Type : Chassis Mount
Termination Style : Terminal Block
Inductance : 320µH
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Packaging : Bulk
Series : BE
Part Status : Active
Connector Style : IEC 320-C14
Connector Type : Receptacle, Male Blades - Module
Current - IEC : 10A
Voltage - IEC : 115/250VAC
Current - UL : -
Voltage - UL : -
Filter Type : Filtered (EMI, RFI) - Commercial, Medical
Fuse : No
Number of Positions : 3
Mounting Type : Panel Mount, Flange
Termination : Quick Connect
Switch Features : Switch On-Off
Features : -
Fuse Holder, Drawer : -
Panel Cutout Dimensions : Rectangular - 28.50mm x 39.00mm
Panel Thickness : -
Material Flammability Rating : -
Ingress Protection : -
Approvals : CSA, UL, VDE
0
38 in stock
