Grayhill, Inc.
- Grayhill, Inc. is a leading manufacturer of electronic components including, optical and mechanical encoders, rotary switches, joysticks, surface mount and thru-hole DIP switches, rotary DIP switches, toggle switches, standard & custom keypads, custom operator interface front panels, I/O modules, and mounting racks.
Part Number
Manufacturer
Description
Unit Price
In Stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : 56
Part Status : Active
Number of Positions : 2 ~ 5
Index Stops : Adjustable
Number of Decks : 1
Number of Poles per Deck : 2
Circuit per Deck : DP5T
Contact Timing : Non-Shorting (BBM)
Current Rating : 200mA (AC/DC)
Voltage Rating - AC : 115V
Voltage Rating - DC : 30V
Actuator Type : Flatted (3.17mm Dia)
Actuator Length : 9.53mm
Angle of Throw : 36°
Contact Material : Brass
Contact Finish : Silver
Mounting Type : Panel Mount
Termination Style : Solder Lug
Features : Shaft and Panel Sealed
Depth Behind Panel : 12.19mm
0
59 in stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : 56
Part Status : Active
Number of Positions : 2 ~ 5
Index Stops : Adjustable
Number of Decks : 1
Number of Poles per Deck : 2
Circuit per Deck : DP5T
Contact Timing : Shorting (MBB)
Current Rating : 200mA (AC/DC)
Voltage Rating - AC : 115V
Voltage Rating - DC : 30V
Actuator Type : Flatted (3.17mm Dia)
Actuator Length : 9.53mm
Angle of Throw : 36°
Contact Material : Brass
Contact Finish : Silver
Mounting Type : Panel Mount
Termination Style : Solder Lug
Features : Shaft and Panel Sealed
Depth Behind Panel : 12.19mm
0
21 in stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : -
Part Status : Active
Type : Rotary Shaft Seal
For Use With/Related Products : -
Features : -
Mounting Feature : -
Thread Size : -
Size / Dimension : 0.275" (6.99mm) Height
Actuator Diameter : -
Color : -
Material : -
Operating Temperature : -
Ingress Protection : -
0
100 in stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : -
Part Status : Active
Style : -
Type : -
Shaft Size : -
Diameter : -
Height : -
Indicator : -
Material : -
Color : -
Features : -
0
80 in stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : -
Part Status : Active
Style : -
Type : -
Shaft Size : -
Diameter : -
Height : -
Indicator : -
Material : -
Color : -
Features : -
0
14 in stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : 60A
Part Status : Active
Encoder Type : Optical
Output Type : Quadrature (Incremental)
Pulses per Revolution : 20
Voltage - Supply : 4.75 V ~ 5.25 V
Actuator Type : 1/8" Dia Flatted End
Detent : Yes
Built in Switch : Yes
Mounting Type : Panel Mount
Orientation : Vertical
Termination Style : Cable with Connector
Rotational Life (Cycles Min) : 1M
0
11 in stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : 60A
Part Status : Active
Encoder Type : Optical
Output Type : Quadrature (Incremental)
Pulses per Revolution : 20
Voltage - Supply : 4.75 V ~ 5.25 V
Actuator Type : 1/8" Dia Flatted End
Detent : Yes
Built in Switch : Yes
Mounting Type : Panel Mount
Orientation : Vertical
Termination Style : Cable with Connector
Rotational Life (Cycles Min) : 1M
0
5 in stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : 60A
Part Status : Active
Encoder Type : Optical
Output Type : Quadrature (Incremental)
Pulses per Revolution : 20
Voltage - Supply : 4.75 V ~ 5.25 V
Actuator Type : 1/4" Dia Flatted End
Detent : Yes
Built in Switch : Yes
Mounting Type : Panel Mount
Orientation : Vertical
Termination Style : Cable with Connector
Rotational Life (Cycles Min) : 1M
0
8 in stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : 60A
Part Status : Active
Encoder Type : Optical
Output Type : Quadrature, 2-Bit
Pulses per Revolution : 20
Voltage - Supply : 5V
Actuator Type : 6mm Dia Flatted End
Detent : Yes
Built in Switch : Yes
Mounting Type : Panel Mount
Orientation : User Selectable
Termination Style : Connector
Rotational Life (Cycles Min) : 1M
0
37 in stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : 60A
Part Status : Active
Encoder Type : Optical
Output Type : Quadrature (Incremental)
Pulses per Revolution : 20
Voltage - Supply : 4.75 V ~ 5.25 V
Actuator Type : 1/8" Dia Flatted End
Detent : Yes
Built in Switch : Yes
Mounting Type : Panel Mount
Orientation : Vertical
Termination Style : Cable with Connector
Rotational Life (Cycles Min) : 1M
0
3 in stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : 60A
Part Status : Active
Encoder Type : Optical
Output Type : Quadrature, 2-Bit
Pulses per Revolution : 20
Voltage - Supply : 5V
Actuator Type : 6mm Dia Flatted End
Detent : Yes
Built in Switch : Yes
Mounting Type : Panel Mount
Orientation : User Selectable
Termination Style : Connector
Rotational Life (Cycles Min) : 1M
0
42 in stock
Grayhill, Inc.
Manufacturer : Grayhill Inc.
Series : 60AD
Part Status : Active
Encoder Type : Optical
Output Type : Quadrature (Incremental)
Pulses per Revolution : 20
Voltage - Supply : 5V
Actuator Type : 1/4" Dia Flatted End
Detent : Yes
Built in Switch : Yes
Mounting Type : Panel Mount
Orientation : Vertical
Termination Style : Cable with Connector
Rotational Life (Cycles Min) : 1M
0
140 in stock
