IXYS Corporation
- IXYS Corporation/Littelfuse has gained a worldwide reputation as a premier power semiconductor manufacturer. Its diversified product base of specialized power semiconductors, integrated circuits and RF power include low on-resistance Power MOSFETs, Ultra Fast switching IGBTs, Fast Recovery Diodes (FREDs), SCR and Diode Modules, Rectifier Bridges, and Power Interface ICs for applications ranging across industrial, transportation, telecommunications, computer, medical, consumer and clean tech markets.
With the acquisition of IXYS, Littelfuse significantly expands the breadth of its power semiconductor portfolio, with solutions spanning a full range of technologies. This diverse portfolio will provide customers with the best technology and enhanced, differentiated capabilities in target markets and geographies as well as deliver greater industry access and increased growth opportunities.
Part Number
Manufacturer
Description
Unit Price
In Stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Bulk
Series : -
Part Status : Active
Diode Type : Avalanche
Voltage - DC Reverse (Vr) (Max) : 1600V
Current - Average Rectified (Io) : 49A
Voltage - Forward (Vf) (Max) @ If : 1.55V @ 150A
Speed : Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 4mA @ 1600V
Capacitance @ Vr, F : -
Mounting Type : Chassis, Stud Mount
Package / Case : DO-203AB, DO-5, Stud
Supplier Device Package : DO-203AB
Operating Temperature - Junction : -40°C ~ 180°C
0
303 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Bulk
Series : -
Part Status : Active
Diode Type : Avalanche
Voltage - DC Reverse (Vr) (Max) : 1600V
Current - Average Rectified (Io) : 110A
Voltage - Forward (Vf) (Max) @ If : 1.17V @ 150A
Speed : Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 6mA @ 1600V
Capacitance @ Vr, F : -
Mounting Type : Chassis, Stud Mount
Package / Case : DO-203AB, DO-5, Stud
Supplier Device Package : DO-203AB
Operating Temperature - Junction : -40°C ~ 180°C
0
100 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 1600V
Current - Average Rectified (Io) : 63A
Voltage - Forward (Vf) (Max) @ If : 4.1V @ 70A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 300ns
Current - Reverse Leakage @ Vr : 2mA @ 1600V
Capacitance @ Vr, F : -
Mounting Type : Through Hole
Package / Case : TO-247-2
Supplier Device Package : TO-247AD
Operating Temperature - Junction : -40°C ~ 150°C
0
207 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 1800V
Current - Average Rectified (Io) : 63A
Voltage - Forward (Vf) (Max) @ If : 4.1V @ 70A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 300ns
Current - Reverse Leakage @ Vr : 2mA @ 1800V
Capacitance @ Vr, F : -
Mounting Type : Through Hole
Package / Case : TO-247-2
Supplier Device Package : TO-247AD
Operating Temperature - Junction : -40°C ~ 150°C
0
420 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : HiPerFRED™
Part Status : Active
Diode Configuration : 1 Pair Common Cathode
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 1200V
Current - Average Rectified (Io) (per Diode) : 15A
Voltage - Forward (Vf) (Max) @ If : 2.74V @ 15A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 40ns
Current - Reverse Leakage @ Vr : 100µA @ 1200V
Operating Temperature - Junction : -55°C ~ 175°C
Mounting Type : Through Hole
Package / Case : TO-3P-3 Full Pack
Supplier Device Package : TO-247AD
0
25 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : HiPerFRED™
Part Status : Active
Diode Configuration : 1 Pair Common Cathode
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 600V
Current - Average Rectified (Io) (per Diode) : 30A
Voltage - Forward (Vf) (Max) @ If : 1.6V @ 30A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 35ns
Current - Reverse Leakage @ Vr : 250µA @ 600V
Operating Temperature - Junction : -55°C ~ 175°C
Mounting Type : Through Hole
Package / Case : TO-3P-3 Full Pack
Supplier Device Package : TO-247AD
0
100 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : HiPerFRED™
Part Status : Active
Diode Configuration : 1 Pair Series Connection
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 1200V
Current - Average Rectified (Io) (per Diode) : 30A
Voltage - Forward (Vf) (Max) @ If : 2.5V @ 30A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 30ns
Current - Reverse Leakage @ Vr : 200µA @ 1200V
Operating Temperature - Junction : -55°C ~ 175°C
Mounting Type : Through Hole
Package / Case : TO-3P-3 Full Pack
Supplier Device Package : TO-247AD
0
100 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : FRED
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 600V
Current - Average Rectified (Io) : 77A
Voltage - Forward (Vf) (Max) @ If : 1.3V @ 70A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 50ns
Current - Reverse Leakage @ Vr : 3mA @ 600V
Capacitance @ Vr, F : -
Mounting Type : Through Hole
Package / Case : TO-247-2
Supplier Device Package : TO-247AD
Operating Temperature - Junction : -40°C ~ 150°C
0
61 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 1200V
Current - Average Rectified (Io) : 75A
Voltage - Forward (Vf) (Max) @ If : 1.8V @ 70A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 60ns
Current - Reverse Leakage @ Vr : 3mA @ 1200V
Capacitance @ Vr, F : -
Mounting Type : Through Hole
Package / Case : TO-247-2
Supplier Device Package : TO-247AD
Operating Temperature - Junction : -40°C ~ 150°C
0
100 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 600V
Current - Average Rectified (Io) : 14A
Voltage - Forward (Vf) (Max) @ If : 1.7V @ 16A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 50ns
Current - Reverse Leakage @ Vr : 50µA @ 600V
Capacitance @ Vr, F : -
Mounting Type : Through Hole
Package / Case : TO-220-2
Supplier Device Package : TO-220AC
Operating Temperature - Junction : -40°C ~ 150°C
0
178 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 1000V
Current - Average Rectified (Io) : 12A
Voltage - Forward (Vf) (Max) @ If : 2.7V @ 12A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 60ns
Current - Reverse Leakage @ Vr : 250µA @ 1000V
Capacitance @ Vr, F : -
Mounting Type : Through Hole
Package / Case : TO-220-2
Supplier Device Package : TO-220AC
Operating Temperature - Junction : -40°C ~ 150°C
0
639 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 1200V
Current - Average Rectified (Io) : 11A
Voltage - Forward (Vf) (Max) @ If : 2.6V @ 12A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 70ns
Current - Reverse Leakage @ Vr : 250µA @ 1200V
Capacitance @ Vr, F : -
Mounting Type : Through Hole
Package / Case : TO-220-2
Supplier Device Package : TO-220AC
Operating Temperature - Junction : -40°C ~ 150°C
0
6987 in stock
