Luminus Devices, Inc.
- Luminus Devices, Inc. develops and markets solid-state lighting solutions (SSL) to help its customers migrate from conventional lamp technologies to long-life and energy-efficient LED illumination. Luminus offers a comprehensive range of LED solutions for indoor and outdoor illumination markets as well as high-output specialty lighting solutions for performance-driven markets including consumer displays, entertainment lighting, medical and industrial applications. Luminus is headquartered in Sunnyvale, CA, and has operations in Woburn, Massachusetts and Xiamen, China.
Part Number
Manufacturer
Description
Unit Price
In Stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 6500K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 825 lm (800 lm ~ 850 lm)
Current - Test : 3.15A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 81 lm/W
Current - Max : 9A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 6500K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 825 lm (800 lm ~ 850 lm)
Current - Test : 3.15A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 81 lm/W
Current - Max : 9A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 6500K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 825 lm (800 lm ~ 850 lm)
Current - Test : 3.15A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 81 lm/W
Current - Max : 9A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Alternate Packaging
Series : SST-90
Part Status : Active
Color : White, Cool
CCT (K) : 6500K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 975 lm (950 lm ~ 1000 lm)
Current - Test : 3.15A
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 95 lm/W
CRI (Color Rendering Index) : 70
Current - Max : 9A
Viewing Angle : 100°
Mounting Type : Surface Mount
Package / Case : 3-SMD, No Lead
Supplier Device Package : -
Size / Dimension : 0.433" L x 0.394" W (11.00mm x 10.00mm)
Height - Seated (Max) : 0.067" (1.71mm)
0
19 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tape & Reel (TR)
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 6500K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 3.15A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : -
Current - Max : 9A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tape & Reel (TR)
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 6500K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 3.15A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : -
Current - Max : 9A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tape & Reel (TR)
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 6500K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 3.15A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : -
Current - Max : 9A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 3.15A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : -
Current - Max : 9A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 3.15A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : -
Current - Max : 9A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 3.15A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : -
Current - Max : 9A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 3.15A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : -
Current - Max : 9A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 3.15A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : -
Current - Max : 9A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
