Mallory Sonalert Products
- Headquartered in a new 22,000 square foot facility in Indianapolis, Indiana, Mallory Sonalert Products, Inc. is a leader in the manufacture and development of Sonalert® electronic audible signal products. The company has made its trademarked Sonalert line for over thirty years. In addition to sonalert products, Mallory also distributes a full range of audible signal devices including transducers, indicators, sirens, buzzers and related hardware to a broad range of customers in industrial, military and consumer electronic markets.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : ZT
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 16 ~ 28V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Pin Selectable, Visual Indicator
Duration : Variable
Sound Pressure Level (SPL) : 85dB @ 16V, 61cm
Current - Supply : 40mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : cUL, UL
Ratings : -
Ingress Protection : NEMA 3R, 4X, 12
Mounting Type : -
Termination : -
Size / Dimension : -
Height - Seated (Max) : -
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : ZT
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 16 ~ 28V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Pin Selectable, Visual Indicator
Duration : Variable
Sound Pressure Level (SPL) : 85dB @ 16V, 61cm
Current - Supply : 40mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : cUL, UL
Ratings : -
Ingress Protection : NEMA 3R, 4X, 12
Mounting Type : -
Termination : -
Size / Dimension : -
Height - Seated (Max) : -
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : ZT
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 16 ~ 28V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Pin Selectable, Visual Indicator
Duration : Variable
Sound Pressure Level (SPL) : 85dB @ 16V, 61cm
Current - Supply : 40mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : cUL, UL
Ratings : -
Ingress Protection : NEMA 3R, 4X, 12
Mounting Type : -
Termination : -
Size / Dimension : -
Height - Seated (Max) : -
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : ZT
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC
Voltage - Rated : -
Voltage Range : 90 ~ 120V
Frequency : 3.7kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : -
Sound Pressure Level (SPL) : 85dB @ 90V, 61cm
Current - Supply : 40mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : cUL, UL
Ratings : -
Ingress Protection : NEMA 3R, 4X, 12
Mounting Type : Panel Mount
Termination : Terminal Block
Size / Dimension : 1.210" Dia (30.74mm)
Height - Seated (Max) : 2.234" (56.75mm)
0
7 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : ZT
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC
Voltage - Rated : -
Voltage Range : 90 ~ 120V
Frequency : 3.7kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : -
Sound Pressure Level (SPL) : 85dB @ 90V, 61cm
Current - Supply : 40mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : cUL, UL
Ratings : -
Ingress Protection : NEMA 3R, 4X, 12
Mounting Type : Panel Mount
Termination : Terminal Block
Size / Dimension : 1.210" Dia (30.74mm)
Height - Seated (Max) : 2.234" (56.75mm)
0
9 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : ZT
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC
Voltage - Rated : -
Voltage Range : 90 ~ 120V
Frequency : 3.7kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : -
Sound Pressure Level (SPL) : 85dB @ 90V, 61cm
Current - Supply : 40mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : cUL, UL
Ratings : -
Ingress Protection : NEMA 3R, 4X, 12
Mounting Type : Panel Mount
Termination : Terminal Block
Size / Dimension : 1.210" Dia (30.74mm)
Height - Seated (Max) : 2.234" (56.75mm)
0
7 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : ZT
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC
Voltage - Rated : -
Voltage Range : 90 ~ 120V
Frequency : 3.7kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : 15 Sec On-Time
Sound Pressure Level (SPL) : 85dB @ 90V, 61cm
Current - Supply : 40mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : cUL, UL
Ratings : -
Ingress Protection : NEMA 3R, 4X, 12
Mounting Type : Panel Mount
Termination : Terminal Block
Size / Dimension : 1.210" Dia (30.74mm)
Height - Seated (Max) : 2.234" (56.75mm)
0
12 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : ZT
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC
Voltage - Rated : -
Voltage Range : 90 ~ 120V
Frequency : 3.7kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : 30 Sec On-Time
Sound Pressure Level (SPL) : 85dB @ 90V, 61cm
Current - Supply : 40mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : cUL, UL
Ratings : -
Ingress Protection : NEMA 3R, 4X, 12
Mounting Type : Panel Mount
Termination : Terminal Block
Size / Dimension : 1.210" Dia (30.74mm)
Height - Seated (Max) : 2.234" (56.75mm)
0
8 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : ZT
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC
Voltage - Rated : -
Voltage Range : 90 ~ 120V
Frequency : 3.7kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : -
Sound Pressure Level (SPL) : 85dB @ 90V, 61cm
Current - Supply : 40mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : cUL, UL
Ratings : -
Ingress Protection : NEMA 3R, 4X, 12
Mounting Type : Panel Mount
Termination : Terminal Block
Size / Dimension : 1.210" Dia (30.74mm)
Height - Seated (Max) : 2.234" (56.75mm)
0
10 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : -
Series : ZT
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC
Voltage - Rated : -
Voltage Range : 90 ~ 120V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Pulse, Fast
Duration : 10 PPS
Sound Pressure Level (SPL) : 85dB @ 90V, 61cm
Current - Supply : 40mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : cUL
Ratings : -
Ingress Protection : NEMA 3R, 4X, 12
Mounting Type : Panel Mount
Termination : Terminal Block
Size / Dimension : 1.210" Dia (30.74mm)
Height - Seated (Max) : 2.234" (56.75mm)
0
100 in stock
