Mill-Max Mfg. Corp.
- Mill-Max Mfg. Corp., located at 190 Pine Hollow Road, Oyster Bay, NY 11771, is a vertically integrated engineering and manufacturing company capable of producing over 100 million interconnect components a week, making us the largest manufacturer of precision machined interconnect components in North America.
Established in 1971 by Roger Bahnik, Chairman and CEO, Mill-Max has a tradition of exercising total control from raw materials to finished product. Our 150,000 square foot plant houses all facilities including: engineering, tooling, primary and secondary machining, stamping, gold and tin plating, injection molding, automatic assembly operations and strict process control, monitored by our experienced Quality Control Inspectors.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 291
Part Status : Active
Tail Type : No Tail
Termination : Press-Fit, Hex
Length - Overall : 0.145" (3.68mm)
Accepts Pin Diameter : 0.022" ~ 0.034" (0.56mm ~ 0.86mm)
Accepts Square Pin Size : 0.025" (0.64mm)
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.067" (1.70mm)
Flange Diameter : 0.079" (2.01mm)
Tail Diameter : -
Socket Depth : 0.120" (3.05mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
100 in stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 292
Part Status : Active
Tail Type : No Tail
Termination : Solder
Length - Overall : 0.250" (6.35mm)
Accepts Pin Diameter : 0.022" ~ 0.032" (0.56mm ~ 0.81mm)
Accepts Square Pin Size : -
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.071" (1.80mm)
Flange Diameter : 0.093" (2.36mm)
Tail Diameter : -
Socket Depth : 0.210" (5.33mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
34514 in stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 292
Part Status : Active
Tail Type : No Tail
Termination : Solder
Length - Overall : 0.250" (6.35mm)
Accepts Pin Diameter : 0.022" ~ 0.032" (0.56mm ~ 0.81mm)
Accepts Square Pin Size : -
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.071" (1.80mm)
Flange Diameter : 0.093" (2.36mm)
Tail Diameter : -
Socket Depth : 0.210" (5.33mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
6398 in stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 293
Part Status : Active
Tail Type : No Tail
Termination : Press-Fit
Length - Overall : 0.200" (5.08mm)
Accepts Pin Diameter : 0.022" ~ 0.034" (0.56mm ~ 0.86mm)
Accepts Square Pin Size : 0.025" (0.64mm)
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.067" (1.70mm)
Flange Diameter : 0.086" (2.18mm)
Tail Diameter : -
Socket Depth : 0.170" (4.32mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
1450 in stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 0293
Part Status : Active
Tail Type : No Tail
Termination : Press-Fit
Length - Overall : 0.200" (5.08mm)
Accepts Pin Diameter : 0.022" ~ 0.034" (0.56mm ~ 0.86mm)
Accepts Square Pin Size : 0.025" (0.64mm)
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.067" (1.70mm)
Flange Diameter : 0.086" (2.18mm)
Tail Diameter : -
Socket Depth : 0.170" (4.32mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
900 in stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 294
Part Status : Active
Tail Type : No Tail
Termination : Solder
Length - Overall : 0.206" (5.23mm)
Accepts Pin Diameter : 0.022" ~ 0.032" (0.56mm ~ 0.81mm)
Accepts Square Pin Size : -
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.076" (1.93mm)
Flange Diameter : 0.090" (2.29mm)
Tail Diameter : -
Socket Depth : 0.185" (4.70mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
100350 in stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 294
Part Status : Active
Tail Type : No Tail
Termination : Solder
Length - Overall : 0.206" (5.23mm)
Accepts Pin Diameter : 0.022" ~ 0.032" (0.56mm ~ 0.81mm)
Accepts Square Pin Size : -
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.076" (1.93mm)
Flange Diameter : 0.090" (2.29mm)
Tail Diameter : -
Socket Depth : 0.185" (4.70mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
21626 in stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 295
Part Status : Active
Tail Type : No Tail
Termination : Solder
Length - Overall : 0.259" (6.58mm)
Accepts Pin Diameter : 0.022" ~ 0.032" (0.56mm ~ 0.81mm)
Accepts Square Pin Size : -
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.063" (1.60mm)
Flange Diameter : 0.077" (1.96mm)
Tail Diameter : -
Socket Depth : 0.233" (5.92mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
48461 in stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 295
Part Status : Active
Tail Type : No Tail
Termination : Solder
Length - Overall : 0.259" (6.58mm)
Accepts Pin Diameter : 0.022" ~ 0.032" (0.56mm ~ 0.81mm)
Accepts Square Pin Size : -
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.063" (1.60mm)
Flange Diameter : 0.077" (1.96mm)
Tail Diameter : -
Socket Depth : 0.233" (5.92mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
53840 in stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 300
Part Status : Active
Tail Type : Standard Tail
Termination : Solder
Length - Overall : 0.320" (8.13mm)
Accepts Pin Diameter : 0.025" ~ 0.037" (0.64mm ~ 0.94mm)
Accepts Square Pin Size : 0.025" (0.64mm)
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.042" (1.07mm)
Flange Diameter : 0.078" (1.98mm)
Tail Diameter : 0.040" (1.02mm)
Socket Depth : 0.180" (4.57mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
59500 in stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 300
Part Status : Active
Tail Type : Standard Tail
Termination : Solder
Length - Overall : 0.320" (8.13mm)
Accepts Pin Diameter : 0.025" ~ 0.037" (0.64mm ~ 0.94mm)
Accepts Square Pin Size : 0.025" (0.64mm)
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.042" (1.07mm)
Flange Diameter : 0.078" (1.98mm)
Tail Diameter : 0.040" (1.02mm)
Socket Depth : 0.180" (4.57mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
23153 in stock
Mill-Max
Manufacturer : Mill-Max Manufacturing Corp.
Packaging : Bulk
Series : 300
Part Status : Active
Tail Type : Standard Tail
Termination : Solder
Length - Overall : 0.397" (10.10mm)
Accepts Pin Diameter : 0.025" ~ 0.037" (0.64mm ~ 0.94mm)
Accepts Square Pin Size : 0.025" (0.64mm)
Pin Hole Diameter : 0.051" (1.30mm)
Mounting Hole Diameter : 0.042" (1.07mm)
Flange Diameter : 0.078" (1.98mm)
Tail Diameter : 0.040" (1.02mm)
Socket Depth : 0.180" (4.57mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : 30.0µin (0.76µm)
0
3955 in stock
