Murata Power Solutions
- Murata Power Solutions designs and manufactures DC/DC Converters, AC/DC Power Supplies, Magnetics, Data Acquisition devices and Digital Panel Meters, and offers these products in custom, standard and modified-standard variations. Currently the world's number 1 supplier of DC/DC converters and one of the top 5 largest suppliers of power electronics overall, our products are used within numerous applications including telecommunications, computing, industrial, medical, office-equipment and more.
Murata Power Solutions was formed in 2007 when Murata Manufacturing Corporation acquired the power electronics division of C&D Technologies. We are headquartered in Mansfield, Massachusetts (USA) with over 1,300 employees in locations in the USA, Canada, Mexico, England, France, Germany, Japan, China and Singapore.
Part Number
Manufacturer
Description
Unit Price
In Stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Tube
Series : UCQ
Part Status : Obsolete
Type : Isolated Module
Number of Outputs : 1
Voltage - Input (Min) : 36V
Voltage - Input (Max) : 75V
Voltage - Output 1 : 3.3V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 20A
Power (Watts) : 66W
Voltage - Isolation : 2.25kV
Applications : ITE (Commercial)
Features : Remote On/Off, OTP, OVP, SCP
Operating Temperature : -40°C ~ 85°C
Efficiency : 90%
Mounting Type : Through Hole
Package / Case : 8-DIP Module, 1/4 Brick
Size / Dimension : 2.30" L x 1.45" W x 0.40" H (58.4mm x 36.8mm x 10.0mm)
Supplier Device Package : -
Control Features : Enable, Active Low
0
100 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Tube
Series : UCQ
Part Status : Obsolete
Type : Isolated Module
Number of Outputs : 1
Voltage - Input (Min) : 36V
Voltage - Input (Max) : 75V
Voltage - Output 1 : 3.3V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 30A
Power (Watts) : 99W
Voltage - Isolation : 2.25kV
Applications : ITE (Commercial)
Features : Remote On/Off, OTP, OVP, SCP
Operating Temperature : -40°C ~ 85°C
Efficiency : 91%
Mounting Type : Through Hole
Package / Case : 8-DIP Module, 1/4 Brick
Size / Dimension : 2.30" L x 1.45" W x 0.40" H (58.4mm x 36.8mm x 10.0mm)
Supplier Device Package : -
Control Features : Enable, Active Low
0
100 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Tube
Series : UCQ
Part Status : Obsolete
Type : Isolated Module
Number of Outputs : 1
Voltage - Input (Min) : 36V
Voltage - Input (Max) : 75V
Voltage - Output 1 : 3.3V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 30A
Power (Watts) : 99W
Voltage - Isolation : 2.25kV
Applications : ITE (Commercial)
Features : Remote On/Off, OTP, OVP, SCP
Operating Temperature : -40°C ~ 85°C
Efficiency : 91%
Mounting Type : Through Hole
Package / Case : 8-DIP Module, 1/4 Brick
Size / Dimension : 2.30" L x 1.45" W x 0.40" H (58.4mm x 36.8mm x 10.0mm)
Supplier Device Package : -
Control Features : Enable, Active Low
0
100 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Tube
Series : UCQ
Part Status : Obsolete
Type : Isolated Module
Number of Outputs : 1
Voltage - Input (Min) : 36V
Voltage - Input (Max) : 75V
Voltage - Output 1 : 3.3V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 30A
Power (Watts) : 99W
Voltage - Isolation : 2.25kV
Applications : ITE (Commercial)
Features : Remote On/Off, OTP, OVP, SCP
Operating Temperature : -40°C ~ 85°C
Efficiency : 91%
Mounting Type : Through Hole
Package / Case : 8-DIP Module, 1/4 Brick
Size / Dimension : 2.30" L x 1.45" W x 0.40" H (58.4mm x 36.8mm x 10.0mm)
Supplier Device Package : -
Control Features : Enable, Active Low
0
100 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Tube
Series : UCQ
Part Status : Obsolete
Type : Isolated Module
Number of Outputs : 1
Voltage - Input (Min) : 18V
Voltage - Input (Max) : 36V
Voltage - Output 1 : 3.3V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 35A
Power (Watts) : 115W
Voltage - Isolation : 2.25kV
Applications : ITE (Commercial)
Features : Remote On/Off, OTP, OVP, SCP
Operating Temperature : -40°C ~ 85°C
Efficiency : 89%
Mounting Type : Through Hole
Package / Case : 8-DIP Module, 1/4 Brick
Size / Dimension : 2.30" L x 1.45" W x 0.40" H (58.4mm x 36.8mm x 10.0mm)
Supplier Device Package : -
Control Features : Enable, Active High
0
100 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Tube
Series : UCQ
Part Status : Obsolete
Type : Isolated Module
Number of Outputs : 1
Voltage - Input (Min) : 18V
Voltage - Input (Max) : 36V
Voltage - Output 1 : 5V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 20A
Power (Watts) : 100W
Voltage - Isolation : 2.25kV
Applications : ITE (Commercial)
Features : Remote On/Off, OTP, OVP, SCP
Operating Temperature : -40°C ~ 85°C
Efficiency : 91.5%
Mounting Type : Through Hole
Package / Case : 8-DIP Module, 1/4 Brick
Size / Dimension : 2.30" L x 1.45" W x 0.40" H (58.4mm x 36.8mm x 10.0mm)
Supplier Device Package : -
Control Features : Enable, Active High
0
100 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Tube
Series : UCQ
Part Status : Obsolete
Type : Isolated Module
Number of Outputs : 1
Voltage - Input (Min) : 36V
Voltage - Input (Max) : 75V
Voltage - Output 1 : 5V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 20A
Power (Watts) : 100W
Voltage - Isolation : 2.25kV
Applications : ITE (Commercial)
Features : Remote On/Off, OTP, OVP, SCP
Operating Temperature : -40°C ~ 85°C
Efficiency : 92%
Mounting Type : Through Hole
Package / Case : 8-DIP Module, 1/4 Brick
Size / Dimension : 2.30" L x 1.45" W x 0.40" H (58.4mm x 36.8mm x 10.0mm)
Supplier Device Package : -
Control Features : Enable, Active Low
0
29 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : -
Series : UCQ
Part Status : Obsolete
Type : Isolated Module
Number of Outputs : 1
Voltage - Input (Min) : 36V
Voltage - Input (Max) : 75V
Voltage - Output 1 : 5V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 20A
Power (Watts) : 100W
Voltage - Isolation : 2.25kV
Applications : ITE (Commercial)
Features : -
Operating Temperature : -40°C ~ 85°C (With Derating)
Efficiency : 92%
Mounting Type : Through Hole
Package / Case : Quarter Brick
Size / Dimension : 2.30" L x 1.45" W x 0.50" H (58.4mm x 36.8mm x 12.7mm)
Supplier Device Package : Quarter Brick
Control Features : -
0
100 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Tube
Series : UCQ
Part Status : Obsolete
Type : Isolated Module
Number of Outputs : 1
Voltage - Input (Min) : 36V
Voltage - Input (Max) : 75V
Voltage - Output 1 : 5V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 20A
Power (Watts) : 100W
Voltage - Isolation : 2.25kV
Applications : ITE (Commercial)
Features : Remote On/Off, OTP, OVP, SCP
Operating Temperature : -40°C ~ 85°C
Efficiency : 92%
Mounting Type : Through Hole
Package / Case : 8-DIP Module, 1/4 Brick
Size / Dimension : 2.30" L x 1.45" W x 0.40" H (58.4mm x 36.8mm x 10.0mm)
Supplier Device Package : -
Control Features : Enable, Active Low
0
100 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Tube
Series : UCQ
Part Status : Obsolete
Type : Isolated Module
Number of Outputs : 1
Voltage - Input (Min) : 36V
Voltage - Input (Max) : 75V
Voltage - Output 1 : 5V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 20A
Power (Watts) : 100W
Voltage - Isolation : 2.25kV
Applications : ITE (Commercial)
Features : Remote On/Off, OTP, OVP, SCP
Operating Temperature : -40°C ~ 85°C
Efficiency : 92%
Mounting Type : Through Hole
Package / Case : 8-DIP Module, 1/4 Brick
Size / Dimension : 2.30" L x 1.45" W x 0.40" H (58.4mm x 36.8mm x 10.0mm)
Supplier Device Package : -
Control Features : Enable, Active Low
0
100 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Bulk
Series : UCR100
Part Status : Obsolete
Type : Enclosed
Voltage - Input (Min) : 16.8V
Voltage - Input (Max) : 137.5V
Number of Outputs : 1
Voltage - Output 1 : 5.1V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 20A
Power (Watts) : 100W
Voltage - Isolation : -
Applications : ITE (Commercial)
Efficiency : 87%
Operating Temperature : -40°C ~ 71°C
Mounting Type : Chassis Mount
Size / Dimension : 6.77" L x 4.37" W x 0.78" H (171.9mm x 111.0mm x 19.8mm)
0
100 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Bulk
Series : UCR100
Part Status : Obsolete
Type : Enclosed
Voltage - Input (Min) : 16.8V
Voltage - Input (Max) : 137.5V
Number of Outputs : 1
Voltage - Output 1 : 5.1V
Voltage - Output 2 : -
Voltage - Output 3 : -
Voltage - Output 4 : -
Current - Output (Max) : 20A
Power (Watts) : 100W
Voltage - Isolation : -
Applications : ITE (Commercial)
Efficiency : 87%
Operating Temperature : -40°C ~ 71°C
Mounting Type : Chassis Mount
Size / Dimension : 6.77" L x 4.37" W x 0.78" H (171.9mm x 111.0mm x 19.8mm)
0
100 in stock
