PUI Audio, Inc.
- PUI Audio, Inc. is a leading developer, manufacturer and supplier of quality audio devices and components including buzzers, alerts and transducers. Corporate offices, product development, engineering, sales and customer service are located in Dayton, Ohio.
Our growth and product innovation are the results of listening to our customers. With an extensive network of sales representatives, agents and distributors, we provide products and services throughout the world.
Whether your needs are for an off-the-shelf product or a custom design, Projects Unlimited has your sound solution.
Part Number
Manufacturer
Description
Unit Price
In Stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Bulk
Series : X
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 6V
Voltage Range : 1.5 ~ 12V
Frequency : 3.3kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 106dB @ 6V, 10cm
Current - Supply : 9mA
Port Location : Top
Operating Temperature : -30°C ~ 80°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount, Flange
Termination : Wire Leads
Size / Dimension : 1.575" Dia (40.00mm)
Height - Seated (Max) : 0.925" (23.50mm)
0
2304 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Bulk
Series : X
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 32V
Voltage Range : 3 ~ 32V
Frequency : 2.8kHz
Technology : Piezo
Operating Mode : Pulse, Fast
Duration : 3 PPS
Sound Pressure Level (SPL) : 95dB @ 32V, 10cm
Current - Supply : 21mA
Port Location : Side
Operating Temperature : -30°C ~ 80°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount
Termination : Screw Terminal, Quick Connect Tab - 0.187" (4.75mm)
Size / Dimension : 1.575" L x 1.575" W (40.00mm x 40.00mm)
Height - Seated (Max) : 0.925" (23.50mm)
0
18 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Bulk
Series : X
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 20V
Frequency : 3.5kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 99dB @ 12V, 10cm
Current - Supply : 8mA
Port Location : Top
Operating Temperature : -30°C ~ 80°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Custom
Termination : Wire Leads
Size / Dimension : 1.575" L x 1.575" W (40.00mm x 40.00mm)
Height - Seated (Max) : 0.339" (8.60mm)
0
280 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tray
Series : X
Part Status : Obsolete
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 9V
Voltage Range : 3 ~ 20V
Frequency : 2.8kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 95dB @ 9V, 10cm
Current - Supply : 12mA
Port Location : Top
Operating Temperature : -20°C ~ 105°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 1.693" Dia (43.00mm)
Height - Seated (Max) : 0.571" (14.50mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Bulk
Series : X
Part Status : Obsolete
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 6 ~ 16V
Frequency : 3.1kHz
Technology : Piezo
Operating Mode : Siren
Duration : -
Sound Pressure Level (SPL) : 115dB @ 12V, 10cm
Current - Supply : 65mA
Port Location : Top
Operating Temperature : -20°C ~ 60°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount, Flange
Termination : Wire Leads
Size / Dimension : 1.969" Dia (50.00mm)
Height - Seated (Max) : 1.516" (38.50mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tray
Series : X
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 6V
Voltage Range : 3 ~ 12V
Frequency : 2.8kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 100dB @ 6V, 10cm
Current - Supply : 20mA
Port Location : Top
Operating Temperature : -20°C ~ 60°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount
Termination : Wire Leads
Size / Dimension : 2.087" Dia (53.00mm)
Height - Seated (Max) : 1.240" (31.50mm)
0
62 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tray
Series : X
Part Status : Obsolete
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 6V
Voltage Range : 3 ~ 12V
Frequency : 2.8kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 100dB @ 6V, 10cm
Current - Supply : 20mA
Port Location : Top
Operating Temperature : -20°C ~ 60°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount
Termination : Wire Leads
Size / Dimension : 2.087" Dia (53.00mm)
Height - Seated (Max) : 1.240" (31.50mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Bulk
Series : X
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 5 ~ 15V
Frequency : 3kHz
Technology : Piezo
Operating Mode : Siren
Duration : -
Sound Pressure Level (SPL) : 125dB @ 12V, 10cm
Current - Supply : 200mA
Port Location : User Defined
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Bracket Mount
Termination : Wire Leads
Size / Dimension : 2.224" L x 1.732" W (56.50mm x 44.00mm)
Height - Seated (Max) : 1.555" (39.50mm)
0
20 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Bulk
Series : XL
Part Status : Obsolete
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 7 ~ 15V
Frequency : 3kHz
Technology : Piezo
Operating Mode : Pulse, Slow
Duration : 1.2 PPS
Sound Pressure Level (SPL) : 112dB @ 12V, 10cm
Current - Supply : 200mA
Port Location : User Defined
Operating Temperature : -20°C ~ 60°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Bracket Mount
Termination : Wire Leads
Size / Dimension : 2.264" L x 1.752" W (57.50mm x 44.50mm)
Height - Seated (Max) : 1.594" (40.50mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tray
Series : X
Part Status : Obsolete
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 6V
Voltage Range : -
Frequency : 2.8kHz
Technology : Piezo
Operating Mode : -
Duration : -
Sound Pressure Level (SPL) : -
Current - Supply : -
Port Location : -
Operating Temperature : -
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount
Termination : -
Size / Dimension : -
Height - Seated (Max) : -
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Bulk
Series : X
Part Status : Obsolete
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : -
Frequency : -
Technology : Piezo
Operating Mode : -
Duration : -
Sound Pressure Level (SPL) : -
Current - Supply : -
Port Location : -
Operating Temperature : -
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.984" Dia (25.00mm)
Height - Seated (Max) : 0.917" (23.30mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : -
Series : -
Part Status : Obsolete
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 15V
Frequency : 3kHz
Technology : Piezo
Operating Mode : -
Duration : -
Sound Pressure Level (SPL) : -
Current - Supply : -
Port Location : -
Operating Temperature : -
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : -
Termination : -
Size / Dimension : -
Height - Seated (Max) : -
0
100 in stock
