Samsung Semiconductor
- Samsung Semiconductor's business aims to achieve excellence as a long life, energy saving and eco-friendly light source supplier in displays and lighting applications. Samsung's advanced semiconductor manufacturing expertise serves as a strong foundation to deliver state-of-the-art LED devices. Samsung offers LED based lighting solutions in the form of back light units in display panels, exterior and dashboard lighting in automotives, lighting packages and engines with and without integrated optics, and drivers.
Part Number
Manufacturer
Description
Unit Price
In Stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : Finger-SQ64B
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1360 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 12V
Lumens/Watt @ Current - Test : 162 lm/W
Current - Max : 1.6A
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 230.00mm L x 273.00mm W
Height : 6.70mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : Finger-SQ64B
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1310 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 11.5V
Lumens/Watt @ Current - Test : 163 lm/W
Current - Max : 1.6A
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 259.00mm L x 250.00mm W
Height : 6.70mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : Finger-RT64B
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1360 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 12V
Lumens/Watt @ Current - Test : 162 lm/W
Current - Max : 1.6A
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 259.00mm L x 250.00mm W
Height : 6.70mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : Finger-RT64B
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1310 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 11.5V
Lumens/Watt @ Current - Test : 163 lm/W
Current - Max : 1.6A
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 230.00mm L x 273.00mm W
Height : 6.70mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : -
Series : LT-Q562A
Part Status : Active
Type : LED Engine
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 2000 lm (Typ)
Current - Test : 450mA
Temperature - Test : 40°C
Voltage - Forward (Vf) (Typ) : 21.9V
Lumens/Watt @ Current - Test : 203 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 560.00mm L x 18.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
614 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Box
Series : LT-H282A
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1365 lm (Typ)
Current - Test : 300mA
Temperature - Test : 50°C
Voltage - Forward (Vf) (Typ) : 34.3V
Lumens/Watt @ Current - Test : 133 lm/W
Current - Max : 360mA
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 280.00mm L x 24.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Box
Series : LAM-SQ30B
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1440 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 15.3V
Lumens/Watt @ Current - Test : 134 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 80
Viewing Angle : 145°
Features : With Connector
Size / Dimension : 259.00mm L x 250.00mm W
Height : 6.70mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : LAM-SQ30B
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1360 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 15.3V
Lumens/Watt @ Current - Test : 127 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 80
Viewing Angle : 145°
Features : With Connector
Size / Dimension : 259.00mm L x 250.00mm W
Height : 6.70mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Box
Series : LAM-RT30B
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1440 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 15.3V
Lumens/Watt @ Current - Test : 134 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 80
Viewing Angle : 145°
Features : With Connector
Size / Dimension : 216.00mm L x 273.00mm W
Height : 6.60mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : LAM-RT30B
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1360 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 15.3V
Lumens/Watt @ Current - Test : 127 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 80
Viewing Angle : 145°
Features : With Connector
Size / Dimension : 216.00mm L x 273.00mm W
Height : 6.70mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : LT-M552A
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1530 lm (Typ)
Current - Test : 450mA
Temperature - Test : 50°C
Voltage - Forward (Vf) (Typ) : 24.7V
Lumens/Watt @ Current - Test : 138 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 550.00mm L x 18.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : LT-M562A
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1530 lm (Typ)
Current - Test : 450mA
Temperature - Test : 50°C
Voltage - Forward (Vf) (Typ) : 24.7V
Lumens/Watt @ Current - Test : 138 lm/W
Current - Max : 450mA
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 560.00mm L x 18.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
176 in stock
