Sanken Electric Co., Ltd.
- Sanken Electric Co., Ltd., a leading global supplier of analog power semiconductor products, designs and manufactures a wide range of power management ICs, motor control ICs, LED lighting ICs as well as high quality automotive semiconductor devices and discrete components.
Part Number
Manufacturer
Description
Unit Price
In Stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 3 N and 3 P-Channel (3-Phase Bridge)
FET Feature : Logic Level Gate
Drain to Source Voltage (Vdss) : 60V
Current - Continuous Drain (Id) @ 25°C : 10A, 6A
Rds On (Max) @ Id, Vgs : 140 mOhm @ 5A, 4V
Vgs(th) (Max) @ Id : -
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 460pF @ 10V
Power - Max : 5W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP w/fin
0
495 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 3 N and 3 P-Channel (3-Phase Bridge)
FET Feature : Logic Level Gate
Drain to Source Voltage (Vdss) : 60V
Current - Continuous Drain (Id) @ 25°C : 10A
Rds On (Max) @ Id, Vgs : 140 mOhm @ 5A, 4V
Vgs(th) (Max) @ Id : -
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 460pF @ 10V
Power - Max : 5W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP w/fin
0
1526 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 4 N-Channel
FET Feature : Standard
Drain to Source Voltage (Vdss) : 60V
Current - Continuous Drain (Id) @ 25°C : 7A
Rds On (Max) @ Id, Vgs : 100 mOhm @ 3.5A, 10V
Vgs(th) (Max) @ Id : 2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 660pF @ 10V
Power - Max : 4.8W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 15-SIP Exposed Tab, Formed Leads
Supplier Device Package : 15-ZIP
0
797 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 4 N-Channel
FET Feature : Standard
Drain to Source Voltage (Vdss) : 60V
Current - Continuous Drain (Id) @ 25°C : 7A
Rds On (Max) @ Id, Vgs : 100 mOhm @ 3.5A, 10V
Vgs(th) (Max) @ Id : 2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 660pF @ 10V
Power - Max : 4.8W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 15-SIP
Supplier Device Package : 15-SIP
0
20 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 6 N-Channel (3-Phase Bridge)
FET Feature : Standard
Drain to Source Voltage (Vdss) : 60V
Current - Continuous Drain (Id) @ 25°C : 7A
Rds On (Max) @ Id, Vgs : 100 mOhm @ 3.5A, 10V
Vgs(th) (Max) @ Id : 2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 660pF @ 10V
Power - Max : 5W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 15-SIP
Supplier Device Package : 15-SIP
0
25 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 6 N-Channel (3-Phase Bridge)
FET Feature : Standard
Drain to Source Voltage (Vdss) : 60V
Current - Continuous Drain (Id) @ 25°C : 7A
Rds On (Max) @ Id, Vgs : 100 mOhm @ 3.5A, 10V
Vgs(th) (Max) @ Id : 2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 660pF @ 10V
Power - Max : 5W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 15-SIP Exposed Tab, Formed Leads
Supplier Device Package : 15-ZIP
0
642 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 6 N-Channel (3-Phase Bridge)
FET Feature : Logic Level Gate
Drain to Source Voltage (Vdss) : 60V
Current - Continuous Drain (Id) @ 25°C : 5A
Rds On (Max) @ Id, Vgs : 300 mOhm @ 3A, 4V
Vgs(th) (Max) @ Id : 2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 320pF @ 10V
Power - Max : 5W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 15-SIP Exposed Tab, Formed Leads
Supplier Device Package : 15-ZIP
0
465 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 4 N-Channel (Half Bridge)
FET Feature : Logic Level Gate
Drain to Source Voltage (Vdss) : 60V
Current - Continuous Drain (Id) @ 25°C : 5A
Rds On (Max) @ Id, Vgs : 300 mOhm @ 3A, 4V
Vgs(th) (Max) @ Id : 2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 320pF @ 10V
Power - Max : 4.8W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 15-SIP Exposed Tab, Formed Leads
Supplier Device Package : 15-ZIP
0
662 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 6 N-Channel (3-Phase Bridge)
FET Feature : Standard
Drain to Source Voltage (Vdss) : 500V
Current - Continuous Drain (Id) @ 25°C : 5A
Rds On (Max) @ Id, Vgs : 1.4 Ohm @ 2.5A, 10V
Vgs(th) (Max) @ Id : 4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 770pF @ 10V
Power - Max : 5W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 15-SIP Exposed Tab, Formed Leads
Supplier Device Package : 15-ZIP
0
75 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Not For New Designs
FET Type : 5 N-Channel, Common Source
FET Feature : Logic Level Gate
Drain to Source Voltage (Vdss) : 60V
Current - Continuous Drain (Id) @ 25°C : 10A
Rds On (Max) @ Id, Vgs : 220 mOhm @ 3A, 4V
Vgs(th) (Max) @ Id : 2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 320pF @ 10V
Power - Max : 5W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP w/fin
0
922 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Not For New Designs
FET Type : 5 P-Channel, Common Source
FET Feature : Logic Level Gate
Drain to Source Voltage (Vdss) : 60V
Current - Continuous Drain (Id) @ 25°C : 5A
Rds On (Max) @ Id, Vgs : 220 mOhm @ 3A, 10V
Vgs(th) (Max) @ Id : 2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 790pF @ 10V
Power - Max : 5W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP w/fin
0
227 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 3 N and 3 P-Channel (3-Phase Bridge)
FET Feature : Standard
Drain to Source Voltage (Vdss) : 600V
Current - Continuous Drain (Id) @ 25°C : 7A
Rds On (Max) @ Id, Vgs : -
Vgs(th) (Max) @ Id : -
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : -
Power - Max : -
Operating Temperature : -
Mounting Type : Through Hole
Package / Case : 15-SIP Exposed Tab, Formed Leads
Supplier Device Package : 15-ZIP
0
103 in stock
