Sanyo Denki
- Sanyo Denki America is your ultimate source for cutting-edge thermal management solutions. Since 1927, Sanyo Denki has been surpassing the ever-increasing cooling demands of customers all over the world by providing industry-leading reliability and performance. In the 21st century, Sanyo Denki continues to thrive in leading the industry with a commitment to total customer satisfaction and the success of our business partners.
Part Number
Manufacturer
Description
Unit Price
In Stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 60
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 20.00mm
Air Flow : 18.4 CFM (0.515m鲁/min)
Static Pressure : 0.180 in H2O (44.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 29.0 dB(A)
Power (Watts) : 960mW
RPM : 4100 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.154 lb (69.85g)
0
1447 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 60
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 20.00mm
Air Flow : 12.0 CFM (0.336m鲁/min)
Static Pressure : 0.080 in H2O (20.0 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 18.0 dB(A)
Power (Watts) : 720mW
RPM : 2700 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.154 lb (69.85g)
0
86 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 60
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 20.00mm
Air Flow : 31.1 CFM (0.871m鲁/min)
Static Pressure : 0.500 in H2O (124.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : PWM Control, Speed Sensor (Tach)
Noise : 43.0 dB(A)
Power (Watts) : 2.88W
RPM : 6850 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.154 lb (69.85g)
0
1558 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 60
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 20.00mm
Air Flow : 24.7 CFM (0.692m鲁/min)
Static Pressure : 0.326 in H2O (81.2 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : PWM Control, Speed Sensor (Tach)
Noise : 36.0 dB(A)
Power (Watts) : 1.68W
RPM : 5500 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.154 lb (69.85g)
0
319 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 60
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.00mm
Air Flow : 24.0 CFM (0.672m鲁/min)
Static Pressure : 0.320 in H2O (79.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Noise : 38.0 dB(A)
Power (Watts) : 1.92W
RPM : 5900 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CSA, UL
Weight : -
0
47 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 70
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 70mm L x 70mm H
Width : 38.00mm
Air Flow : 93.6 CFM (2.62m鲁/min)
Static Pressure : 3.453 in H2O (860.1 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : PWM Control, Speed Sensor (Tach)
Noise : 65.0 dB(A)
Power (Watts) : 31.20W
RPM : 16500 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.375 lb (170.1g)
0
439 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 70
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 70mm L x 70mm H
Width : 38.00mm
Air Flow : 67.8 CFM (1.90m鲁/min)
Static Pressure : 1.830 in H2O (455.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : PWM Control, Speed Sensor (Tach)
Noise : 57.0 dB(A)
Power (Watts) : 13.20W
RPM : 1200 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.375 lb (170.1g)
0
278 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 32.00mm
Air Flow : -
Static Pressure : -
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection, Speed Sensor (Tach)
Noise : -
Power (Watts) : -
RPM : -
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 32.00mm
Air Flow : -
Static Pressure : -
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection, Speed Sensor (Tach)
Noise : -
Power (Watts) : -
RPM : -
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 32.00mm
Air Flow : -
Static Pressure : -
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection
Noise : -
Power (Watts) : -
RPM : -
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 32.00mm
Air Flow : -
Static Pressure : -
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection
Noise : -
Power (Watts) : -
RPM : -
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 32.00mm
Air Flow : -
Static Pressure : -
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Sensor
Noise : -
Power (Watts) : -
RPM : -
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
