Sanyo Denki
- Sanyo Denki America is your ultimate source for cutting-edge thermal management solutions. Since 1927, Sanyo Denki has been surpassing the ever-increasing cooling demands of customers all over the world by providing industry-leading reliability and performance. In the 21st century, Sanyo Denki continues to thrive in leading the industry with a commitment to total customer satisfaction and the success of our business partners.
Part Number
Manufacturer
Description
Unit Price
In Stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 51.5 CFM (1.44m鲁/min)
Static Pressure : 0.352 in H2O (87.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Noise : 37.0 dB(A)
Power (Watts) : 2.64W
RPM : 5200 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.243 lb (110.22g)
0
343 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 73.0 CFM (2.04m鲁/min)
Static Pressure : 0.700 in H2O (174.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Noise : 48.0 dB(A)
Power (Watts) : 7.20W
RPM : 7400 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.243 lb (110.22g)
0
660 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 20.00mm
Air Flow : 60.8 CFM (1.70m鲁/min)
Static Pressure : 0.440 in H2O (109.6 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : PWM Control, Speed Sensor (Tach)
Noise : 45.0 dB(A)
Power (Watts) : 3.60W
RPM : 5850 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.176 lb (79.83g)
0
1179 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 20.00mm
Air Flow : 29.7 CFM (0.832m鲁/min)
Static Pressure : 0.110 in H2O (27.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : PWM Control, Speed Sensor (Tach)
Noise : 26.5 dB(A)
Power (Watts) : 720mW
RPM : 2900 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.176 lb (79.83g)
0
193 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 15.00mm
Air Flow : 50.9 CFM (1.43m鲁/min)
Static Pressure : 0.337 in H2O (83.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : PWM Control, Speed Sensor (Tach)
Noise : 41.0 dB(A)
Power (Watts) : 3.48W
RPM : 6100 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.143 lb (64.86g)
0
100 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 15.00mm
Air Flow : 41.7 CFM (1.17m鲁/min)
Static Pressure : 0.226 in H2O (56.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : PWM Control, Speed Sensor (Tach)
Noise : 37.0 dB(A)
Power (Watts) : 2.04W
RPM : 5000 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CSA, TUV, UL
Weight : 0.143 lb (64.86g)
0
60 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 32.00mm
Air Flow : -
Static Pressure : -
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection, Speed Sensor (Tach)
Noise : -
Power (Watts) : -
RPM : -
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 32.00mm
Air Flow : -
Static Pressure : -
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection, Speed Sensor (Tach)
Noise : -
Power (Watts) : -
RPM : -
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 32.00mm
Air Flow : -
Static Pressure : -
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection
Noise : -
Power (Watts) : -
RPM : -
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 32.00mm
Air Flow : -
Static Pressure : -
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection
Noise : -
Power (Watts) : -
RPM : -
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 32.00mm
Air Flow : -
Static Pressure : -
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Sensor
Noise : -
Power (Watts) : -
RPM : -
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
Sanyo Denki
Manufacturer : Sanyo Denki America Inc.
Series : San Ace 80
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 32.00mm
Air Flow : -
Static Pressure : -
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection, Speed Sensor (Tach)
Noise : -
Power (Watts) : -
RPM : -
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
