VersaLogic Corporation
VersaLogic Corporation is the trusted name in embedded computer products. Featuring 5 to 10 year availability, -40 to +85° C operating temperature, Mil Standard 202G shock and vibration testing, and outstanding US-based support, VersaLogic products are ideal for critical applications that value ruggedness, reliability and long life.
Part Number
Manufacturer
Description
Unit Price
In Stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : FOX
Part Status : Active
Core Processor : Vortex86DX2
Speed : 933MHz
Number of Cores : 1
Power (Watts) : 7.0W
Cooling Type : Heat Sink
Size / Dimension : 3.77" x 4.23" (96mm x 108mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
RAM Capacity/Installed : 512MB/512MB
Storage Interface : SATA (1), Mini PCIe/mSATA, microSD
Video Outputs : VGA, LVDS
Ethernet : 10/100 Mbps (2)
USB : USB 2.0 (4)
RS-232 (422, 485) : 4
Digital I/O Lines : 8
Analog Input:Output : 0:0
Watchdog Timer : Yes
Operating Temperature : 0°C ~ 60°C
0
100 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : FOX
Part Status : Active
Core Processor : Vortex86DX2
Speed : 933MHz
Number of Cores : 1
Power (Watts) : 7.1W
Cooling Type : Heat Sink
Size / Dimension : 3.77" x 4.23" (96mm x 108mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
RAM Capacity/Installed : 1GB/1GB
Storage Interface : SATA (1), Mini PCIe/mSATA, microSD
Video Outputs : VGA, LVDS
Ethernet : 10/100 Mbps (2)
USB : USB 2.0 (4)
RS-232 (422, 485) : 4
Digital I/O Lines : 8
Analog Input:Output : 0:0
Watchdog Timer : Yes
Operating Temperature : 0°C ~ 60°C
0
100 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Tiger
Part Status : Obsolete
Core Processor : Atom Z520PT
Speed : 1.33GHz
Number of Cores : 1
Power (Watts) : 5.9W
Cooling Type : Heat Sink
Size / Dimension : 3.6" x 3.8" (90mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus noPassThru
RAM Capacity/Installed : 2GB/0GB
Storage Interface : ATA100, IDE DOM
Video Outputs : LVDS
Ethernet : 10/100 Mbps (1)
USB : USB 2.0 (7)
RS-232 (422, 485) : 4
Digital I/O Lines : 0
Analog Input:Output : 0:0
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
292 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Tiger
Part Status : Obsolete
Core Processor : Atom Z520PT
Speed : 1.33GHz
Number of Cores : 1
Power (Watts) : 5.9W
Cooling Type : Heat Sink
Size / Dimension : 3.6" x 3.8" (90mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus noPassThru
RAM Capacity/Installed : 2GB/0GB
Storage Interface : ATA100, IDE DOM
Video Outputs : LVDS
Ethernet : 10/100 Mbps (1)
USB : USB 2.0 (7)
RS-232 (422, 485) : 4
Digital I/O Lines : 0
Analog Input:Output : 0:0
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
116 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Tiger
Part Status : Obsolete
Core Processor : Atom Z530P
Speed : 1.6GHz
Number of Cores : 1
Power (Watts) : 5W
Cooling Type : Heat Sink
Size / Dimension : 3.6" x 3.8" (90mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus noPassThru
RAM Capacity/Installed : 2GB/0GB
Storage Interface : ATA100, IDE DOM
Video Outputs : LVDS
Ethernet : 10/100 Mbps (1)
USB : USB 2.0 (7)
RS-232 (422, 485) : 4
Digital I/O Lines : 0
Analog Input:Output : 0:0
Watchdog Timer : Yes
Operating Temperature : 0°C ~ 60°C
0
100 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Tiger
Part Status : Obsolete
Core Processor : Atom Z530P
Speed : 1.6GHz
Number of Cores : 1
Power (Watts) : 6.0W
Cooling Type : Heat Sink
Size / Dimension : 3.6" x 3.8" (90mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus noPassThru
RAM Capacity/Installed : 2GB/0GB
Storage Interface : ATA100, IDE DOM
Video Outputs : LVDS
Ethernet : 10/100 Mbps (1)
USB : USB 2.0 (7)
RS-232 (422, 485) : 4
Digital I/O Lines : 0
Analog Input:Output : 0:0
Watchdog Timer : Yes
Operating Temperature : 0°C ~ 60°C
0
100 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : BayCat
Part Status : Active
Core Processor : Atom E3815
Speed : 1.46GHz
Number of Cores : 1
Power (Watts) : 5.15W
Cooling Type : Heat plate
Size / Dimension : 4.23" x 3.77" (108mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
RAM Capacity/Installed : 8GB/0GB
Storage Interface : SATA, mSATA, SD
Video Outputs : HDMI, VGA
Ethernet : 10/100/1000 Mbps (2)
USB : USB 2.0 (4), USB 3.0 (1)
RS-232 (422, 485) : 2
Digital I/O Lines : 24
Analog Input:Output : -
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
2 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : BayCat
Part Status : Active
Core Processor : Atom E3826
Speed : 1.46GHz
Number of Cores : 2
Power (Watts) : 5.2W
Cooling Type : Heat plate
Size / Dimension : 4.23" x 3.77" (108mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
RAM Capacity/Installed : 8GB/0GB
Storage Interface : SATA, mSATA, SD
Video Outputs : HDMI, VGA
Ethernet : 10/100/1000 Mbps (2)
USB : USB 2.0 (4), USB 3.0 (1)
RS-232 (422, 485) : 2
Digital I/O Lines : 24
Analog Input:Output : -
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
8 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : BayCat
Part Status : Active
Core Processor : Atom E3845
Speed : 1.91GHz
Number of Cores : 4
Power (Watts) : 6.5W
Cooling Type : Heat plate
Size / Dimension : 4.23" x 3.77" (108mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
RAM Capacity/Installed : 8GB/0GB
Storage Interface : SATA, mSATA, SD
Video Outputs : HDMI, VGA
Ethernet : 10/100/1000 Mbps (2)
USB : USB 2.0 (4), USB 3.0 (1)
RS-232 (422, 485) : 2
Digital I/O Lines : 24
Analog Input:Output : -
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
41 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Cheetah
Part Status : Obsolete
Core Processor : Pentium M 745
Speed : 1.8GHz
Number of Cores : 1
Power (Watts) : 25W
Cooling Type : Fan
Size / Dimension : 3.6" x 3.8" (90mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
RAM Capacity/Installed : 1GB/0GB
Storage Interface : ATA100, CompactFlash
Video Outputs : VGA, LVDS
Ethernet : 10/100 Mbps (1)
USB : USB 2.0 (2)
RS-232 (422, 485) : 2
Digital I/O Lines : 0
Analog Input:Output : 0:0
Watchdog Timer : Yes
Operating Temperature : 0°C ~ 60°C
0
100 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Cheetah
Part Status : Obsolete
Core Processor : Pentium M 745
Speed : 1.0GHz
Number of Cores : 1
Power (Watts) : 12W
Cooling Type : Fan
Size / Dimension : 3.6" x 3.8" (90mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
RAM Capacity/Installed : 1GB/0GB
Storage Interface : ATA100, CompactFlash
Video Outputs : VGA, LVDS
Ethernet : 10/100 Mbps (1)
USB : USB 2.0 (2)
RS-232 (422, 485) : 2
Digital I/O Lines : 0
Analog Input:Output : 0:0
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
100 in stock
VersaLogic Corporation
Manufacturer : VersaLogic Corporation
Series : Cheetah
Part Status : Obsolete
Core Processor : ULV Celeron M 373
Speed : 1.0GHz
Number of Cores : 1
Power (Watts) : 8W
Cooling Type : Heat Sink
Size / Dimension : 3.6" x 3.8" (90mm x 96mm)
Form Factor : PC/104
Expansion Site/Bus : PC/104-Plus
RAM Capacity/Installed : 1GB/0GB
Storage Interface : ATA100, CompactFlash
Video Outputs : VGA, LVDS
Ethernet : 10/100 Mbps (1)
USB : USB 2.0 (2)
RS-232 (422, 485) : 2
Digital I/O Lines : 0
Analog Input:Output : 0:0
Watchdog Timer : Yes
Operating Temperature : -40°C ~ 85°C
0
100 in stock
