Ametherm
- Ametherm is a leading manufacturer of Power Thermistors. Ametherm offers the highest rated steady state current rating as well as highest rated energy handling capability offered in the market. Their excellent long-term stability and rugged structure makes them ideally suited for limiting Inrush current in the motors (1/3 HP to 3.0 HP range), medical (Power supplies, MRI), Security systems (X-Ray machines), transformers (up to 8.0 KVA), telecom (Power supplies up to 4000 watt out put power) and motor drives, in the most cost effective method.
Part Number
Manufacturer
Description
Unit Price
In Stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : -
Part Status : Active
Resistance in Ohms @ 25°C : 100
Resistance Tolerance : ±10%
B Value Tolerance : ±3%
B0/50 : 2859K
B25/50 : 2891K
B25/75 : 2910K
B25/85 : 2916K
B25/100 : 2924K
Operating Temperature : -40°C ~ 150°C
Power - Max : 500mW
Length - Lead Wire : 1.50" (38.00mm)
Mounting Type : Through Hole
Package / Case : Disc, 2.5mm Dia x 1.5mm W
0
405 in stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : -
Part Status : Active
Resistance in Ohms @ 25°C : 1k
Resistance Tolerance : ±10%
B Value Tolerance : ±3%
B0/50 : 3445K
B25/50 : 3485K
B25/75 : 3512K
B25/85 : 3521K
B25/100 : 3532K
Operating Temperature : -40°C ~ 150°C
Power - Max : 500mW
Length - Lead Wire : 1.50" (38.00mm)
Mounting Type : Through Hole
Package / Case : Disc, 2.5mm Dia x 1.5mm W
0
356 in stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : -
Part Status : Active
Resistance in Ohms @ 25°C : 10k
Resistance Tolerance : ±10%
B Value Tolerance : ±2%
B0/50 : 3892K
B25/50 : 3934K
B25/75 : 3960K
B25/85 : 3988K
B25/100 : 3999K
Operating Temperature : -40°C ~ 150°C
Power - Max : 500mW
Length - Lead Wire : 1.50" (38.00mm)
Mounting Type : Through Hole
Package / Case : Disc, 2.5mm Dia x 0.8mm W
0
474 in stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : -
Part Status : Active
Resistance in Ohms @ 25°C : 10k
Resistance Tolerance : ±10%
B Value Tolerance : ±2%
B0/50 : 3880K
B25/50 : 3950K
B25/75 : 3968K
B25/85 : 3974K
B25/100 : 3986K
Operating Temperature : -55°C ~ 150°C
Power - Max : 500mW
Length - Lead Wire : 1.50" (38.00mm)
Mounting Type : Through Hole
Package / Case : Disc, 2.5mm Dia x 0.8mm W
0
1558 in stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : -
Part Status : Active
Resistance in Ohms @ 25°C : 5k
Resistance Tolerance : ±10%
B Value Tolerance : ±3%
B0/50 : 3892K
B25/50 : 3934K
B25/75 : 3960K
B25/85 : 3988K
B25/100 : 3999K
Operating Temperature : -40°C ~ 150°C
Power - Max : 500mW
Length - Lead Wire : 1.50" (38.00mm)
Mounting Type : Through Hole
Package / Case : Disc, 2.5mm Dia x 2.0mm W
0
465 in stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : -
Part Status : Active
Resistance in Ohms @ 25°C : 100k
Resistance Tolerance : ±10%
B Value Tolerance : ±3%
B0/50 : 4369K
B25/50 : 4447K
B25/75 : 4505K
B25/85 : 4526K
B25/100 : 4555K
Operating Temperature : -40°C ~ 150°C
Power - Max : 500mW
Length - Lead Wire : 1.00" (25.40mm)
Mounting Type : Through Hole
Package / Case : Disc, 2.5mm Dia x 24.1mm W
0
967 in stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : -
Part Status : Active
Resistance in Ohms @ 25°C : 1k
Resistance Tolerance : ±10%
B Value Tolerance : ±3%
B0/50 : 3445K
B25/50 : 3485K
B25/75 : 3512K
B25/85 : 3521K
B25/100 : 3532K
Operating Temperature : -40°C ~ 150°C
Power - Max : 750mW
Length - Lead Wire : 1.50" (38.00mm)
Mounting Type : Through Hole
Package / Case : Disc, 5.1mm Dia x 0.6mm W
0
282 in stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : Accu-Curve™
Part Status : Active
Resistance in Ohms @ 25°C : 2.252k
Resistance Tolerance : ±0.88%
B Value Tolerance : ±1%
B0/50 : 3892K
B25/50 : 3934K
B25/75 : 3960K
B25/85 : 3988K
B25/100 : 3999K
Operating Temperature : 0°C ~ 70°C
Power - Max : 250mW
Length - Lead Wire : 2.00" (50.8mm)
Mounting Type : Free Hanging
Package / Case : Bead
0
172 in stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : Accu-Curve™
Part Status : Active
Resistance in Ohms @ 25°C : 5k
Resistance Tolerance : ±0.88%
B Value Tolerance : ±1%
B0/50 : 3892K
B25/50 : 3934K
B25/75 : 3960K
B25/85 : 3988K
B25/100 : 3999K
Operating Temperature : 0°C ~ 70°C
Power - Max : 250mW
Length - Lead Wire : 2.00" (50.8mm)
Mounting Type : Free Hanging
Package / Case : Bead
0
392 in stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : Accu-Curve™
Part Status : Active
Resistance in Ohms @ 25°C : 10k
Resistance Tolerance : ±0.88%
B Value Tolerance : ±1%
B0/50 : 3892K
B25/50 : 3934K
B25/75 : 3960K
B25/85 : 3988K
B25/100 : 3999K
Operating Temperature : 0°C ~ 70°C
Power - Max : 250mW
Length - Lead Wire : 2.00" (50.8mm)
Mounting Type : Free Hanging
Package / Case : Bead
0
196 in stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : Accu-Curve™
Part Status : Active
Resistance in Ohms @ 25°C : 2.252k
Resistance Tolerance : ±2.20%
B Value Tolerance : ±1%
B0/50 : 3892K
B25/50 : 3934K
B25/75 : 3960K
B25/85 : 3988K
B25/100 : 3999K
Operating Temperature : 0°C ~ 70°C
Power - Max : 250mW
Length - Lead Wire : 2.00" (50.8mm)
Mounting Type : Free Hanging
Package / Case : Bead
0
190 in stock
Ametherm
Manufacturer : Ametherm
Packaging : Bulk
Series : Accu-Curve™
Part Status : Active
Resistance in Ohms @ 25°C : 5k
Resistance Tolerance : ±2.22%
B Value Tolerance : ±1%
B0/50 : 3892K
B25/50 : 3934K
B25/75 : 3960K
B25/85 : 3988K
B25/100 : 3999K
Operating Temperature : 0°C ~ 70°C
Power - Max : 250mW
Length - Lead Wire : 2.00" (50.8mm)
Mounting Type : Free Hanging
Package / Case : Bead
0
187 in stock
