Delta Electronics
- Delta Group is the world's largest provider of switching power supplies and brushless fans, as well as a major source for power management solutions, components, visual displays, industrial automation, networking products, and renewable energy solutions. Established in 1971, Delta Group has sales offices worldwide and manufacturing plants in Taiwan, Thailand, China, Mexico and Europe. As a global leader in power electronics, Delta's mission is "To provide innovative, clean and efficient energy solutions for a better tomorrow." Delta is committed to environmental protection and has implemented green, lead-free production and recycling and waste management programs for many years.
Part Number
Manufacturer
Description
Unit Price
In Stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 20.00mm
Air Flow : 20.3 CFM (0.568m鲁/min)
Static Pressure : 0.303 in H2O (75.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 40.5 dB(A)
Power (Watts) : 1.92W
RPM : 7000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.084 lb (38.1g)
0
660 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 20.00mm
Air Flow : 20.3 CFM (0.568m鲁/min)
Static Pressure : 0.303 in H2O (75.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 40.5 dB(A)
Power (Watts) : 1.92W
RPM : 7000 RPM
Termination : 2 Wire Leads
Ingress Protection : IP55 - Dust Protected, Water Resistant
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.084 lb (38.1g)
0
597 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 15.00mm
Air Flow : 14.1 CFM (0.395m鲁/min)
Static Pressure : 0.240 in H2O (59.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection
Noise : 32.0 dB(A)
Power (Watts) : 1.68W
RPM : 5600 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UR, VDE
Weight : 0.071 lb (32.21g)
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 15.00mm
Air Flow : 16.2 CFM (0.454m鲁/min)
Static Pressure : 0.315 in H2O (78.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 36.0 dB(A)
Power (Watts) : 1.92W
RPM : 6400 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.071 lb (32.21g)
0
381 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 20.00mm
Air Flow : 18.3 CFM (0.512m鲁/min)
Static Pressure : 0.254 in H2O (63.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 37.0 dB(A)
Power (Watts) : 2.16W
RPM : 6400 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.084 lb (38.1g)
0
112 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 15.00mm
Air Flow : 12.4 CFM (0.347m鲁/min)
Static Pressure : 0.180 in H2O (44.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection
Noise : 28.0 dB(A)
Power (Watts) : 1.44W
RPM : 4800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UR, VDE
Weight : 0.071 lb (32.21g)
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 20.00mm
Air Flow : 20.3 CFM (0.568m鲁/min)
Static Pressure : 0.303 in H2O (75.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 40.5 dB(A)
Power (Watts) : 2.40W
RPM : 7000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.084 lb (38.1g)
0
2446 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 20.00mm
Air Flow : 20.3 CFM (0.568m鲁/min)
Static Pressure : 0.303 in H2O (75.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 40.5 dB(A)
Power (Watts) : 2.40W
RPM : 7000 RPM
Termination : 2 Wire Leads
Ingress Protection : IP55 - Dust Protected, Water Resistant
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.084 lb (38.1g)
0
472 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.00mm
Air Flow : 15.4 CFM (0.431m鲁/min)
Static Pressure : 0.155 in H2O (38.6 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 32.0 dB(A)
Power (Watts) : 1.50W
RPM : 4000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CSA, UL, VDE
Weight : 0.098 lb (44.45g)
0
509 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 13.00mm
Air Flow : 21.2 CFM (0.594m鲁/min)
Static Pressure : 0.163 in H2O (40.6 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection, Speed Sensor (Tach)
Noise : 31.5 dB(A)
Power (Watts) : 1.45W
RPM : 4200 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UR, VDE
Weight : 0.074 lb (33.56g)
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.00mm
Air Flow : 17.3 CFM (0.484m鲁/min)
Static Pressure : 0.195 in H2O (48.6 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection
Noise : 35.0 dB(A)
Power (Watts) : 2.00W
RPM : 4500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UR, VDE
Weight : 0.098 lb (44.45g)
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.00mm
Air Flow : 11.5 CFM (0.322m鲁/min)
Static Pressure : 0.087 in H2O (21.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 24.0 dB(A)
Power (Watts) : 650mW
RPM : 3000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.098 lb (44.45g)
0
311 in stock
