Orion Fans
- For nearly two decades Orion Fans, a division of Knight Electronics has been supplying and designing thermal management solutions for demanding applications worldwide. Orion provides one of the industry’s broadest lines of AC, DC fans, blowers, fan trays and accessories. Fast response and short lead times provide customers the right product when they need it. Orion offers price, quality and availability.
Part Number
Manufacturer
Description
Unit Price
In Stock
Orion Fans
Manufacturer : Orion Fans
Series : OD2510
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 25.5mm L x 25.5mm H
Width : 10.00mm
Air Flow : 2.7 CFM (0.076m鲁/min)
Static Pressure : 0.230 in H2O (57.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 31.0 dB
Power (Watts) : -
RPM : 12000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : cURus, TUV
Weight : -
0
1132 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD2510
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 25.5mm L x 25.5mm H
Width : 10.00mm
Air Flow : 1.8 CFM (0.050m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 16.0 dB
Power (Watts) : -
RPM : 8000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : cURus, TUV
Weight : -
0
202 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD2510
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 25.5mm L x 25.5mm H
Width : 10.00mm
Air Flow : 1.5 CFM (0.042m鲁/min)
Static Pressure : 0.070 in H2O (17.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 15.0 dB(A)
Power (Watts) : 840mW
RPM : 7000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 167°F (-20 ~ 75°C)
Approvals : cURus, TUV
Weight : -
0
60 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD2510
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 25.5mm L x 25.5mm H
Width : 10.00mm
Air Flow : 2.2 CFM (0.061m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 24.0 dB
Power (Watts) : -
RPM : 10000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : cURus, TUV
Weight : -
0
1288 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD2510
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 25mm L x 25mm H
Width : 10.00mm
Air Flow : 2.1 CFM (0.059m鲁/min)
Static Pressure : 0.160 in H2O (39.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Sensor
Noise : 24.0 dB
Power (Watts) : 1.44W
RPM : 10000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, cURus
Weight : 0.018 lb (8.16g)
0
160 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD254AP
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Round - 254mm Dia
Width : 89.00mm
Air Flow : 830.0 CFM (23.24m鲁/min)
Static Pressure : 0.780 in H2O (194.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 60.0 dB
Power (Watts) : 65.0W
RPM : 2400 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 167°F (-20 ~ 75°C)
Approvals : cURus, TUV
Weight : -
0
17 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD254AP
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Round - 254mm Dia
Width : 89.00mm
Air Flow : 690.0 CFM (19.32m鲁/min)
Static Pressure : 0.580 in H2O (144.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 47.0 dB
Power (Watts) : 23.00W
RPM : 2000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 167°F (-20 ~ 75°C)
Approvals : cURus, TUV
Weight : -
0
40 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD254AP
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Round - 254mm Dia
Width : 89.00mm
Air Flow : 850.0 CFM (23.80m鲁/min)
Static Pressure : 0.830 in H2O (206.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 64.0 dB
Power (Watts) : 64.0W
RPM : 2500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 167°F (-20 ~ 75°C)
Approvals : cURus, TUV
Weight : -
0
148 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD254AP
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Round - 254mm Dia
Width : 89.00mm
Air Flow : 550.0 CFM (15.40m鲁/min)
Static Pressure : 0.370 in H2O (92.2 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 39.0 dB
Power (Watts) : 13.00W
RPM : 1500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 167°F (-20 ~ 75°C)
Approvals : cURus, TUV
Weight : -
0
16 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD254AP
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Round - 254mm Dia
Width : 89.00mm
Air Flow : 690.0 CFM (19.32m鲁/min)
Static Pressure : 0.580 in H2O (144.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 47.0 dB
Power (Watts) : 24.00W
RPM : 2000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 167°F (-20 ~ 75°C)
Approvals : cURus, TUV
Weight : -
0
121 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD254AP
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Round - 254mm Dia
Width : 89.00mm
Air Flow : 690.0 CFM (19.32m鲁/min)
Static Pressure : 0.580 in H2O (144.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 47.0 dB
Power (Watts) : 24.00W
RPM : 2000 RPM
Termination : 2 Terminals
Ingress Protection : -
Operating Temperature : -4 ~ 167°F (-20 ~ 75°C)
Approvals : cURus, TUV
Weight : -
0
36 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD254AP
Part Status : Active
Voltage - Rated : 48VDC
Size / Dimension : Round - 254mm Dia
Width : 89.00mm
Air Flow : 850.0 CFM (23.80m鲁/min)
Static Pressure : 0.830 in H2O (206.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 64.0 dB
Power (Watts) : 62.0W
RPM : 2500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 167°F (-20 ~ 75°C)
Approvals : cURus, TUV
Weight : -
0
34 in stock
