Orion Fans
- For nearly two decades Orion Fans, a division of Knight Electronics has been supplying and designing thermal management solutions for demanding applications worldwide. Orion provides one of the industry’s broadest lines of AC, DC fans, blowers, fan trays and accessories. Fast response and short lead times provide customers the right product when they need it. Orion offers price, quality and availability.
Part Number
Manufacturer
Description
Unit Price
In Stock
Orion Fans
Manufacturer : Orion Fans
Series : OD9238
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 92.5mm L x 92.5mm H
Width : 38.00mm
Air Flow : 90.0 CFM (2.52m鲁/min)
Static Pressure : 0.340 in H2O (84.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 47.0 dB
Power (Watts) : 12.00W
RPM : 3600 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : cURus, TUV
Weight : 0.463 lb (210.01g)
0
22 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD9238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 92.5mm L x 92.5mm H
Width : 38.00mm
Air Flow : 90.0 CFM (2.52m鲁/min)
Static Pressure : 0.400 in H2O (99.6 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 50.0 dB
Power (Watts) : 13.20W
RPM : 4000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : cURus, TUV
Weight : 0.463 lb (210.01g)
0
1038 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD9238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 92.5mm L x 92.5mm H
Width : 38.00mm
Air Flow : 135.0 CFM (3.78m鲁/min)
Static Pressure : 0.740 in H2O (184.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 58.0 dB
Power (Watts) : 16.00W
RPM : 5400 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : cURus, TUV
Weight : -
0
361 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD9238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 92.5mm L x 92.5mm H
Width : 38.00mm
Air Flow : 135.0 CFM (3.78m鲁/min)
Static Pressure : 0.740 in H2O (184.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : PWM Control, Speed Sensor (Tach)
Noise : 58.0 dB
Power (Watts) : 16.00W
RPM : 5400 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : cURus, TUV
Weight : -
0
374 in stock
Orion Fans
Manufacturer : Orion Fans
Series : OD9238
Part Status : Active
Voltage - Rated : 48VDC
Size / Dimension : Square - 92.5mm L x 92.5mm H
Width : 38.00mm
Air Flow : 135.0 CFM (3.78m鲁/min)
Static Pressure : 0.740 in H2O (184.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 58.0 dB
Power (Watts) : 17.00W
RPM : 5400 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : cURus, TUV
Weight : -
0
182 in stock
Orion Fans
Manufacturer : Orion Fans
Series : -
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Round - 133.5mm Dia
Width : 91.00mm
Air Flow : 257.0 CFM (7.20m鲁/min)
Static Pressure : 1.900 in H2O (473.3 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : PWM Control, Speed Sensor (Tach)
Noise : 68.0 dB
Power (Watts) : 63.6W
RPM : 4600 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 149°F (-10 ~ 65°C)
Approvals : CE, cURus, TUV, UR
Weight : 1.543 lb (700.0g)
0
8 in stock
Orion Fans
Manufacturer : Orion Fans
Series : -
Part Status : Active
Voltage - Rated : 48VDC
Size / Dimension : Round - 133.5mm Dia
Width : 91.00mm
Air Flow : 257.0 CFM (7.20m鲁/min)
Static Pressure : 1.900 in H2O (473.3 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : PWM Control, Speed Sensor (Tach)
Noise : 68.0 dB
Power (Watts) : 60.0W
RPM : 4600 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 149°F (-10 ~ 65°C)
Approvals : CE, cURus, TUV, UR
Weight : 1.543 lb (700.0g)
0
12 in stock
Orion Fans
Manufacturer : Orion Fans
Series : -
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Round - 175mm Dia
Width : 67.00mm
Air Flow : 298.0 CFM (8.34m鲁/min)
Static Pressure : 1.380 in H2O (343.7 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : PWM Control, Speed Sensor (Tach)
Noise : 64.0 dB
Power (Watts) : 50.4W
RPM : 3000 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 149°F (-10 ~ 65°C)
Approvals : CE, TUV
Weight : 1.98 lbs (900g)
0
12 in stock
Orion Fans
Manufacturer : Orion Fans
Series : -
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Round - 175mm Dia
Width : 67.00mm
Air Flow : 298.0 CFM (8.34m鲁/min)
Static Pressure : 1.380 in H2O (343.7 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : PWM Control, Speed Sensor (Tach)
Noise : 64.0 dB
Power (Watts) : 50.4W
RPM : 3000 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 149°F (-10 ~ 65°C)
Approvals : CE, cURus, TUV, UR
Weight : 1.98 lbs (900g)
0
12 in stock
Orion Fans
Manufacturer : Orion Fans
Series : -
Part Status : Active
Voltage - Rated : 48VDC
Size / Dimension : Round - 175mm Dia
Width : 67.00mm
Air Flow : 298.0 CFM (8.34m鲁/min)
Static Pressure : 1.380 in H2O (343.7 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : PWM Control, Speed Sensor (Tach)
Noise : 64.0 dB
Power (Watts) : 50.4W
RPM : 3000 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 149°F (-10 ~ 65°C)
Approvals : CE, cURus, TUV, UR
Weight : 1.98 lbs (900g)
0
12 in stock
Orion Fans
Manufacturer : Orion Fans
Series : ODB182
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Rectangular/Rounded - 171mm L x 182.1mm H
Width : 82.00mm
Air Flow : 136.0 CFM (3.81m鲁/min)
Static Pressure : 2.500 in H2O (622.7 Pa)
Bearing Type : Ball
Fan Type : Blower
Features : -
Noise : 63.0 dB
Power (Watts) : -
RPM : 2000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : cURus
Weight : 2.5 lbs (1.1kg)
0
21 in stock
Orion Fans
Manufacturer : Orion Fans
Series : -
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Round - 189.5mm Dia
Width : 68.50mm
Air Flow : 395.0 CFM (11.06m鲁/min)
Static Pressure : 2.000 in H2O (498.2 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : PWM Control, Speed Sensor (Tach)
Noise : 75.0 dB
Power (Watts) : 108W
RPM : 3200 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 149°F (-10 ~ 65°C)
Approvals : CE, cURus, TUV, UR
Weight : 2.205 lb (1kg)
0
8 in stock
