Bridgelux
- At Bridgelux, we help companies, industries and people experience the power and possibility of light. Since 2002, we’ve designed LED solutions that are high performing, energy efficient, cost effective and easy to integrate. Bridgelux focuses on light’s impact on human behavior, delivering products that create better environments, experiences and returns—both experiential and financial. From our successful Vero® Series to smart lighting, Bridgelux patented technology drives new platforms for commercial and industrial luminaires.
Part Number
Manufacturer
Description
Unit Price
In Stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tube
Series : RS
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 7000 lm (Typ)
Current - Test : 2.8A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 30.9V
Lumens/Watt @ Current - Test : 81 lm/W
Current - Max : 3.75A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 45.60mm L x 50.80mm W
Height : 3.00mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tube
Series : LS
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 265 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 13.2V
Lumens/Watt @ Current - Test : 57 lm/W
Current - Max : 600mA
CRI (Color Rendering Index) : 82
Viewing Angle : 120°
Features : -
Size / Dimension : 13.80mm L x 18.00mm W
Height : 3.00mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : -
Series : LS
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 700mA
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : 1.2A
CRI (Color Rendering Index) : -
Viewing Angle : 120°
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tube
Series : LS
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 295 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 12.6V
Lumens/Watt @ Current - Test : 67 lm/W
Current - Max : 600mA
CRI (Color Rendering Index) : 82 (Typ)
Viewing Angle : 120°
Features : -
Size / Dimension : 13.80mm L x 18.00mm W
Height : 3.00mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : -
Series : LS
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 700mA
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : 1.2A
CRI (Color Rendering Index) : -
Viewing Angle : 120°
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : -
Series : LED
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : -
Current - Test : 900mA
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : 1.5A
CRI (Color Rendering Index) : -
Viewing Angle : 120°
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tube
Series : ES STAR
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 440 lm (Typ)
Current - Test : 700mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 9.5V
Lumens/Watt @ Current - Test : 66 lm/W
Current - Max : 1.5A
CRI (Color Rendering Index) : 82 (Typ)
Viewing Angle : 120°
Features : -
Size / Dimension : 20.04mm L x 20.04 mm W
Height : 3.50mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tube
Series : ES STAR
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 460 lm (Typ)
Current - Test : 700mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 9V
Lumens/Watt @ Current - Test : 73 lm/W
Current - Max : 1.5A
CRI (Color Rendering Index) : 82 (Typ)
Viewing Angle : 120°
Features : -
Size / Dimension : 20.04mm L x 20.04 mm W
Height : 3.50mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : -
Series : ES STAR
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : -
Current - Test : 250mA
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : 500mA
CRI (Color Rendering Index) : -
Viewing Angle : 120°
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tube
Series : LED
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 880 lm (Typ)
Current - Test : 1.3A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 13.2V
Lumens/Watt @ Current - Test : 51 lm/W
Current - Max : 2A
CRI (Color Rendering Index) : 82 (Typ)
Viewing Angle : 120°
Features : -
Size / Dimension : 22.80mm L x 25.80mm W
Height : 3.50mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tube
Series : ES
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 930 lm (Typ)
Current - Test : 1.05A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 12.2V
Lumens/Watt @ Current - Test : 73 lm/W
Current - Max : 2A
CRI (Color Rendering Index) : 82 (Typ)
Viewing Angle : 120°
Features : -
Size / Dimension : 22.80mm L x 25.80mm W
Height : 3.50mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tube
Series : LED
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 1320 lm (Typ)
Current - Test : 1.6A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 16.4V
Lumens/Watt @ Current - Test : 50 lm/W
Current - Max : 2.5A
CRI (Color Rendering Index) : 82 (Typ)
Viewing Angle : 120°
Features : -
Size / Dimension : 22.80mm L x 25.80mm W
Height : 3.50mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
