Opulent Americas
- Opulent Americas, part of Singapore based Opulent Group, is a fully integrated global manufacturer for the lighting, automotive, and medical industries. The company brings 30 years of experience, state of the art manufacturing, full traceability and advanced quality control to every solution. ISO certifications include ISO 9001, ISO 14001, ISO 13485 and ISO 16949.
Opulent's goal is to accelerate the adoption of LED technology through simple, modular products and custom designs. Opulent customers get to market faster, with less resources, at lower costs. The North Carolina based office provides quick engineering and sales support with an R&D lab for prototype development and custom designs servicing the North, Central and South American markets. Full global manufacturing capabilities enable building domestic or overseas at scale.
Part Number
Manufacturer
Description
Unit Price
In Stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : OSLON® Square
Part Status : Active
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 2040 lm (Typ)
Current - Test : 700mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 22.4V
Lumens/Watt @ Current - Test : 130 lm/W
Current - Max : 1.8A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 59.59mm L x 45.01mm W
Height : -
Light Emitting Surface (LES) : -
Lens Type : Flat
0
149 in stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : OSLON® Square
Part Status : Active
Type : LED Module
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 2520 lm (Typ)
Current - Test : 700mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 22.4V
Lumens/Watt @ Current - Test : 160 lm/W
Current - Max : 1.8A
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : -
Size / Dimension : 59.59mm L x 45.01mm W
Height : -
Light Emitting Surface (LES) : -
Lens Type : Flat
0
125 in stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : XHP50.2
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 2700K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 700mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : 90
Viewing Angle : -
Features : -
Size / Dimension : 36.83mm L x 36.83mm W
Height : -
Light Emitting Surface (LES) : -
Lens Type : Domed
0
25 in stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : XHP50.2
Part Status : Active
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 5-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 1120 lm (Typ)
Current - Test : 700mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 11.2V
Lumens/Watt @ Current - Test : 143 lm/W
Current - Max : 1.5A
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : -
Size / Dimension : 36.83mm L x 36.83mm W
Height : -
Light Emitting Surface (LES) : -
Lens Type : Domed
0
24 in stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : XHP50.2
Part Status : Active
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 5-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 1120 lm (Typ)
Current - Test : 700mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 11.2V
Lumens/Watt @ Current - Test : 143 lm/W
Current - Max : 1.5A
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : -
Size / Dimension : 36.83mm L x 36.83mm W
Height : -
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : XHP50.2
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 2700K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 700mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : 90
Viewing Angle : -
Features : -
Size / Dimension : 70.00mm L x 70.00mm W
Height : -
Light Emitting Surface (LES) : -
Lens Type : Domed
0
28 in stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : XHP50.2
Part Status : Active
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 5-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 4480 lm (Typ)
Current - Test : 700mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 44.8V
Lumens/Watt @ Current - Test : 143 lm/W
Current - Max : 1.5A
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : -
Size / Dimension : 70.00mm L x 70.00mm W
Height : -
Light Emitting Surface (LES) : -
Lens Type : Domed
0
50 in stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : XHP50.2
Part Status : Active
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 5-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 4480 lm (Typ)
Current - Test : 700mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 44.8V
Lumens/Watt @ Current - Test : 143 lm/W
Current - Max : 1.5A
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : -
Size / Dimension : 70.00mm L x 70.00mm W
Height : -
Light Emitting Surface (LES) : -
Lens Type : Domed
0
76 in stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : -
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 516mW
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3V
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : -
Viewing Angle : 120°
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : -
0
98 in stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : -
Part Status : Active
Type : Chip On Board (COB)
Color : Red
CCT (K) : -
Wavelength : 735nm
Configuration : Starboard
Flux @ Current/Temperature - Test : 282mW
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 1.85V
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : -
Viewing Angle : 120°
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : -
0
99 in stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : -
Part Status : Active
Type : Chip On Board (COB)
Color : Green
CCT (K) : -
Wavelength : 530nm
Configuration : Starboard
Flux @ Current/Temperature - Test : 281mW
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.2V
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : -
Viewing Angle : 120°
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : -
0
39 in stock
Opulent Americas
Manufacturer : Opulent Americas
Packaging : -
Series : -
Part Status : Active
Type : Chip On Board (COB)
Color : Red
CCT (K) : -
Wavelength : 655nm
Configuration : Starboard
Flux @ Current/Temperature - Test : 450mW
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 2.15V
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : -
Viewing Angle : 120°
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : -
0
241 in stock
