Standex-Meder Electronics
- Standex-Meder Electronics is a worldwide market leader in the design, development and manufacture of standard and custom electro-magnetic components, including magnetics products and reed switch-based solutions.
Our magnetic offerings include planar, Rogowski, current, and low- and high-frequency transformers and inductors. Our reed switch-based solutions include Meder, Standex and OKI brand reed switches, as well as a complete portfolio of reed relays, and a comprehensive array of fluid level, proximity, motion, water flow, HVAC condensate, hydraulic pressure differential, capacitive, conductive and inductive sensors.
Part Number
Manufacturer
Description
Unit Price
In Stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Bulk
Series : KSK
Part Status : Active
Type : Glass Body
Circuit : SPST-NO
Operate Range : 20 ~ 30AT
Release Range : -
Current - Switching : 1A (AC/DC)
Voltage - Switching AC : 1000V
Voltage - Switching DC : 1000V
Power - Rated : 100W
Operate Time : 1.1ms
Release Time : 0.1ms
Mounting Type : Through Hole
Termination Style : Axial
Length - Overall : 2.181" (55.40mm)
Size - Body : 0.108" Dia x 0.827" L (2.75mm x 21.00mm)
Height Above Board : -
Operating Temperature : -40°C ~ 130°C
Capacitance : 0.5pF
Current - Carry : 2.5A (AC/DC)
0
1196 in stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Bulk
Series : KSK
Part Status : Active
Type : Glass Body
Circuit : SPST-NO
Operate Range : 30 ~ 35AT
Release Range : -
Current - Switching : 1A (AC/DC)
Voltage - Switching AC : 1000V
Voltage - Switching DC : 1000V
Power - Rated : 100W
Operate Time : 1.1ms
Release Time : 0.1ms
Mounting Type : Through Hole
Termination Style : Axial
Length - Overall : 2.181" (55.40mm)
Size - Body : 0.108" Dia x 0.827" L (2.75mm x 21.00mm)
Height Above Board : -
Operating Temperature : -40°C ~ 130°C
Capacitance : 0.5pF
Current - Carry : 2.5A (AC/DC)
0
1089 in stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Bulk
Series : KSK
Part Status : Active
Type : Glass Body
Circuit : SPST-NO
Operate Range : 10 ~ 15AT
Release Range : -
Current - Switching : 400mA (AC/DC)
Voltage - Switching AC : 200V
Voltage - Switching DC : 200V
Power - Rated : 10W
Operate Time : 0.6ms
Release Time : 0.1ms
Mounting Type : Through Hole
Termination Style : Axial
Length - Overall : 1.406" (35.70mm)
Size - Body : 0.079" Dia x 0.394" L (2.00mm x 10.00mm)
Height Above Board : -
Operating Temperature : -40°C ~ 130°C
Capacitance : 0.2pF
Current - Carry : 500mA (AC/DC)
0
996 in stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Bulk
Series : KSK
Part Status : Active
Type : Glass Body
Circuit : SPDT
Operate Range : 10 ~ 15AT
Release Range : -
Current - Switching : 500mA (AC/DC)
Voltage - Switching AC : 175V
Voltage - Switching DC : 175V
Power - Rated : 10W
Operate Time : 0.7ms
Release Time : 1.5ms
Mounting Type : Through Hole
Termination Style : Axial
Length - Overall : 2.169" (55.10mm)
Size - Body : 0.100" Dia x 0.551" L (2.54mm x 14.00mm)
Height Above Board : -
Operating Temperature : -40°C ~ 130°C
Capacitance : 1pF
Current - Carry : 1A (AC/DC)
0
100 in stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Bulk
Series : KSK
Part Status : Active
Type : Glass Body
Circuit : SPDT
Operate Range : 15 ~ 20AT
Release Range : -
Current - Switching : 500mA (AC/DC)
Voltage - Switching AC : 175V
Voltage - Switching DC : 175V
Power - Rated : 10W
Operate Time : 0.7ms
Release Time : 1.5ms
Mounting Type : Through Hole
Termination Style : Axial
Length - Overall : 2.169" (55.10mm)
Size - Body : 0.100" Dia x 0.551" L (2.54mm x 14.00mm)
Height Above Board : -
Operating Temperature : -40°C ~ 130°C
Capacitance : 1pF
Current - Carry : 1A (AC/DC)
0
1914 in stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Bulk
Series : KSK
Part Status : Active
Type : Glass Body
Circuit : SPDT
Operate Range : 20 ~ 25AT
Release Range : -
Current - Switching : 500mA (AC/DC)
Voltage - Switching AC : 175V
Voltage - Switching DC : 175V
Power - Rated : 10W
Operate Time : 0.7ms
Release Time : 1.5ms
Mounting Type : Through Hole
Termination Style : Axial
Length - Overall : 2.169" (55.10mm)
Size - Body : 0.100" Dia x 0.551" L (2.54mm x 14.00mm)
Height Above Board : -
Operating Temperature : -40°C ~ 130°C
Capacitance : 1pF
Current - Carry : 1A (AC/DC)
0
8444 in stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Bulk
Series : KSK
Part Status : Active
Type : Glass Body
Circuit : SPDT
Operate Range : 10 ~ 15AT
Release Range : -
Current - Switching : 500mA (AC/DC)
Voltage - Switching AC : 175V
Voltage - Switching DC : 175V
Power - Rated : 10W
Operate Time : 0.7ms
Release Time : 1.5ms
Mounting Type : Through Hole
Termination Style : Axial
Length - Overall : 2.209" (56.10mm)
Size - Body : 0.100" Dia x 0.551" L (2.54mm x 14.00mm)
Height Above Board : -
Operating Temperature : -40°C ~ 130°C
Capacitance : 1pF
Current - Carry : 1A (AC/DC)
0
289 in stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Cut Tape (CT)
Alternate Packaging
Series : KT
Part Status : Active
Coil Type : Non Latching
Coil Current : 63.0mA
Coil Voltage : 5VDC
Contact Form : SPST-NO (1 Form A)
Contact Rating (Current) : 1A
Switching Voltage : 1000VAC, 1000VDC - Max
Turn On Voltage (Max) : 3.5 VDC
Turn Off Voltage (Min) : 0.5 VDC
Operate Time : -
Release Time : -
Features : Sealed - Fully
Mounting Type : Surface Mount
Termination Style : Gull Wing
Operating Temperature : -40°C ~ 100°C
0
12000 in stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Tube
Series : KT
Part Status : Active
Coil Type : Non Latching
Coil Current : 63.0mA
Coil Voltage : 5VDC
Contact Form : SPST-NO (1 Form A)
Contact Rating (Current) : 1A
Switching Voltage : 1000VAC, 1000VDC - Max
Turn On Voltage (Max) : 3.5 VDC
Turn Off Voltage (Min) : 0.5 VDC
Operate Time : -
Release Time : -
Features : Sealed - Fully
Mounting Type : Through Hole
Termination Style : PC Pin
Operating Temperature : -40°C ~ 100°C
0
954 in stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Cut Tape (CT)
Alternate Packaging
Series : KT
Part Status : Active
Coil Type : Non Latching
Coil Current : 25.0mA
Coil Voltage : 12VDC
Contact Form : SPST-NO (1 Form A)
Contact Rating (Current) : 1A
Switching Voltage : 1000VAC, 1000VDC - Max
Turn On Voltage (Max) : 9 VDC
Turn Off Voltage (Min) : 1 VDC
Operate Time : -
Release Time : -
Features : Sealed - Fully
Mounting Type : Surface Mount
Termination Style : Gull Wing
Operating Temperature : -40°C ~ 100°C
0
314 in stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Tube
Series : KT
Part Status : Active
Coil Type : Non Latching
Coil Current : 25.0mA
Coil Voltage : 12VDC
Contact Form : SPST-NO (1 Form A)
Contact Rating (Current) : 1A
Switching Voltage : 1000VAC, 1000VDC - Max
Turn On Voltage (Max) : 9 VDC
Turn Off Voltage (Min) : 1 VDC
Operate Time : -
Release Time : -
Features : Sealed - Fully
Mounting Type : Through Hole
Termination Style : PC Pin
Operating Temperature : -40°C ~ 100°C
0
362 in stock
Standex-Meder Electronics
Manufacturer : Standex-Meder Electronics
Packaging : Cut Tape (CT)
Alternate Packaging
Series : KT
Part Status : Active
Coil Type : Non Latching
Coil Current : 13.3mA
Coil Voltage : 24VDC
Contact Form : SPST-NO (1 Form A)
Contact Rating (Current) : 1A
Switching Voltage : 1000VAC, 1000VDC - Max
Turn On Voltage (Max) : 16 VDC
Turn Off Voltage (Min) : 2.9 VDC
Operate Time : -
Release Time : -
Features : Sealed - Fully
Mounting Type : Surface Mount
Termination Style : Gull Wing
Operating Temperature : -40°C ~ 100°C
0
500 in stock
