Part Number

Manufacturer

Description

Unit Price

In Stock

RS514-1-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 120µH @ 1kHz
Current Rating (Max) : 1A (Typ)
DC Resistance (DCR) (Max) : 200 mOhm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 0.886" L x 0.846" W (22.50mm x 21.50mm)
Height (Max) : 0.520" (13.20mm)
Package / Case : Horizontal, 4 PC Pin

350 in stock

RS514-2-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 30µH @ 1kHz
Current Rating (Max) : 2A (Typ)
DC Resistance (DCR) (Max) : 50 mOhm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 0.886" L x 0.846" W (22.50mm x 21.50mm)
Height (Max) : 0.520" (13.20mm)
Package / Case : Horizontal, 4 PC Pin

450 in stock

RS514-4-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 8µH @ 1kHz
Current Rating (Max) : 4A (Typ)
DC Resistance (DCR) (Max) : 20 mOhm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 0.886" L x 0.846" W (22.50mm x 21.50mm)
Height (Max) : 0.520" (13.20mm)
Package / Case : Horizontal, 4 PC Pin

425 in stock

RS612-0.5-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 200µH @ 1kHz
Current Rating (Max) : 500mA (Typ)
DC Resistance (DCR) (Max) : 650 mOhm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 0.709" L x 0.492" W (18.00mm x 12.50mm)
Height (Max) : 0.787" (20.00mm)
Package / Case : Vertical, 4 PC Pin

100 in stock

RS612-1-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 55µH @ 1kHz
Current Rating (Max) : 1A (Typ)
DC Resistance (DCR) (Max) : 130 mOhm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 0.709" L x 0.492" W (18.00mm x 12.50mm)
Height (Max) : 0.787" (20.00mm)
Package / Case : Vertical, 4 PC Pin

300 in stock

RS612-2-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 13µH @ 1kHz
Current Rating (Max) : 2A (Typ)
DC Resistance (DCR) (Max) : 30 mOhm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 0.709" L x 0.492" W (18.00mm x 12.50mm)
Height (Max) : 0.787" (20.00mm)
Package / Case : Vertical, 4 PC Pin

100 in stock

RS612-4-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 3µH @ 1kHz
Current Rating (Max) : 4A (Typ)
DC Resistance (DCR) (Max) : 10 mOhm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 0.709" L x 0.492" W (18.00mm x 12.50mm)
Height (Max) : 0.787" (20.00mm)
Package / Case : Vertical, 4 PC Pin

100 in stock

RS614-0.5-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 480µH @ 1kHz
Current Rating (Max) : 500mA (Typ)
DC Resistance (DCR) (Max) : 800 mOhm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 0.906" L x 0.610" W (23.00mm x 15.50mm)
Height (Max) : 0.984" (25.00mm)
Package / Case : Vertical, 4 PC Pin

850 in stock

RS614-1-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 120µH @ 1kHz
Current Rating (Max) : 1A (Typ)
DC Resistance (DCR) (Max) : 200 mOhm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 0.906" L x 0.610" W (23.00mm x 15.50mm)
Height (Max) : 0.984" (25.00mm)
Package / Case : Vertical, 4 PC Pin

239 in stock

RS614-2-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 30µH @ 1kHz
Current Rating (Max) : 2A (Typ)
DC Resistance (DCR) (Max) : 50 mOhm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 0.906" L x 0.610" W (23.00mm x 15.50mm)
Height (Max) : 0.984" (25.00mm)
Package / Case : Vertical, 4 PC Pin

850 in stock

RS614-4-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 8µH @ 1kHz
Current Rating (Max) : 4A (Typ)
DC Resistance (DCR) (Max) : 20 mOhm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 0.906" L x 0.610" W (23.00mm x 15.50mm)
Height (Max) : 0.984" (25.00mm)
Package / Case : Vertical, 4 PC Pin

500 in stock

RS622-0.5-02

Schaffner EMC, Inc.

Manufacturer : Schaffner EMC Inc.
Packaging : Tray
Series : RS
Part Status : Not For New Designs
Filter Type : Signal Line
Number of Lines : 2
Impedance @ Frequency : -
Inductance @ Frequency : 900µH @ 1kHz
Current Rating (Max) : 500mA (Typ)
DC Resistance (DCR) (Max) : 1.25 Ohm (Typ)
Voltage Rating - DC : -
Voltage Rating - AC : 250V
Operating Temperature : -40°C ~ 125°C
Ratings : -
Approvals : UR, VDE
Features : -
Mounting Type : Through Hole
Size / Dimension : 1.220" L x 0.709" W (31.00mm x 18.00mm)
Height (Max) : 1.154" (29.30mm)
Package / Case : Vertical, 4 PC Pin

100 in stock
