Mechatronics
- Mechatronics is a manufacturer of brushless cooling fans and thermal solutions headquartered near Seattle, WA. Mechatronics product offering includes AC axial fans, DC axial fans, AC blowers, DC blowers, AC motorized impellers and value-added assemblies. In addition to our standard products, we offer tailored solutions to fit customer specific requirements from minor modifications to fully custom products.
With factories located in Indonesia, Taiwan and China, Mechatronics offers technologically advanced products, superior quality, competitive pricing and exceptional service.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF18JC-4
Part Status : Active
Voltage - Rated : 230VAC
Size / Dimension : Square - 180mm L x 180mm H
Width : 90.00mm
Air Flow : 460.0 CFM (12.88m鲁/min)
Static Pressure : 1.060 in H2O (264.0 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Permanent Split Capacitor Motor
Noise : 59.0 dB(A)
Power (Watts) : 72.0W
RPM : 3400 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -40 ~ 158°F (-40 ~ 70°C)
Approvals : CE, cUL, TUV, UL
Weight : 4.8 lbs (2.2kg)
0
100 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF190A
Part Status : Active
Voltage - Rated : 115VAC
Size / Dimension : Round - 190mm Dia
Width : 70.00mm
Air Flow : 370.0 CFM (10.36m鲁/min)
Static Pressure : 1.200 in H2O (298.9 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : Permanent Split Capacitor Motor
Noise : 63.0 dB(A)
Power (Watts) : 65.0W
RPM : 2700 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -40 ~ 122°F (-40 ~ 50°C)
Approvals : CE, cUL, TUV, UL
Weight : 2.7 lbs (1.2kg)
0
4 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF190A
Part Status : Active
Voltage - Rated : 115VAC
Size / Dimension : Round - 190mm Dia
Width : 70.00mm
Air Flow : 370.0 CFM (10.36m鲁/min)
Static Pressure : 1.200 in H2O (298.9 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : Permanent Split Capacitor Motor, Speed Sensor (Tach)
Noise : 63.0 dB(A)
Power (Watts) : 65.0W
RPM : 2700 RPM
Termination : 5 Wire Leads
Ingress Protection : -
Operating Temperature : -40 ~ 122°F (-40 ~ 50°C)
Approvals : CE, cUL, TUV, UL
Weight : 2.7 lbs (1.2kg)
0
3 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF190A
Part Status : Active
Voltage - Rated : 115VAC
Size / Dimension : Round - 235mm Dia
Width : 87.20mm
Air Flow : 247.0 CFM (6.92m鲁/min)
Static Pressure : 1.500 in H2O (373.6 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : Permanent Split Capacitor Motor
Noise : 63.0 dB(A)
Power (Watts) : 65.0W
RPM : 2700 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -40 ~ 122°F (-40 ~ 50°C)
Approvals : CE, cUL, TUV, UL
Weight : 3.2 lbs (1.5kg)
0
7 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF190APA
Part Status : Obsolete
Voltage - Rated : 230VAC
Size / Dimension : Round - 190mm Dia
Width : 70.00mm
Air Flow : 335.0 CFM (9.38m鲁/min)
Static Pressure : 1.200 in H2O (298.9 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : Permanent Split Capacitor Motor
Noise : 63.0 dB(A)
Power (Watts) : 72.0W
RPM : 2700 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -40 ~ 122°F (-40 ~ 50°C)
Approvals : CE, cUL, TUV, UL
Weight : 2.6 lbs (1.2kg)
0
100 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF190A
Part Status : Active
Voltage - Rated : 230VAC
Size / Dimension : Round - 190mm Dia
Width : 70.00mm
Air Flow : 370.0 CFM (10.36m鲁/min)
Static Pressure : 1.200 in H2O (298.9 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : Permanent Split Capacitor Motor
Noise : 63.0 dB(A)
Power (Watts) : 72.0W
RPM : 2700 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -40 ~ 122°F (-40 ~ 50°C)
Approvals : CE, cUL, TUV, UL
Weight : 2.7 lbs (1.2kg)
0
8 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF190A
Part Status : Active
Voltage - Rated : 230VAC
Size / Dimension : Round - 235mm Dia
Width : 87.20mm
Air Flow : 247.0 CFM (6.92m鲁/min)
Static Pressure : 1.500 in H2O (373.6 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : Permanent Split Capacitor Motor
Noise : 63.0 dB(A)
Power (Watts) : 72.0W
RPM : 2700 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -40 ~ 122°F (-40 ~ 50°C)
Approvals : CE, cUL, TUV, UL
Weight : 3.2 lbs (1.5kg)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF200B
Part Status : Active
Voltage - Rated : 115VAC
Size / Dimension : Square - 225mm L x 225mm H
Width : 80.00mm
Air Flow : 625.0 CFM (17.50m鲁/min)
Static Pressure : 0.810 in H2O (201.8 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : Permanent Split Capacitor Motor
Noise : 61.0 dB(A)
Power (Watts) : 100W
RPM : 3000 RPM
Termination : 4 Terminals
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CE, cUL, TUV, UL
Weight : 3 lbs (1.4kg)
0
100 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF200B
Part Status : Active
Voltage - Rated : 115VAC
Size / Dimension : Square - 225mm L x 225mm H
Width : 80.00mm
Air Flow : 625.0 CFM (17.50m鲁/min)
Static Pressure : 0.810 in H2O (201.8 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : Permanent Split Capacitor Motor, Speed Sensor (Tach)
Noise : 61.0 dB(A)
Power (Watts) : 100W
RPM : 3000 RPM
Termination : 5 Terminals
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CE, cUL, TUV, UL
Weight : 3 lbs (1.4kg)
0
3 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF200B
Part Status : Active
Voltage - Rated : 115VAC
Size / Dimension : Round - 290mm Dia
Width : 80.00mm
Air Flow : 625.0 CFM (17.50m鲁/min)
Static Pressure : 0.810 in H2O (201.8 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : Permanent Split Capacitor Motor
Noise : 61.0 dB(A)
Power (Watts) : 100W
RPM : 3000 RPM
Termination : 4 Wire Leads
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CE, cUL, TUV, UL
Weight : 3 lbs (1.4kg)
0
100 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF200B
Part Status : Active
Voltage - Rated : 230VAC
Size / Dimension : Square - 225mm L x 225mm H
Width : 80.00mm
Air Flow : 625.0 CFM (17.50m鲁/min)
Static Pressure : 0.810 in H2O (201.8 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : Permanent Split Capacitor Motor
Noise : 61.0 dB(A)
Power (Watts) : 80.0W
RPM : 3000 RPM
Termination : 4 Terminals
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CE, cUL, TUV, UL
Weight : 3 lbs (1.4kg)
0
100 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : UF200B
Part Status : Active
Voltage - Rated : 230VAC
Size / Dimension : Square - 225mm L x 225mm H
Width : 80.00mm
Air Flow : 625.0 CFM (17.50m鲁/min)
Static Pressure : 0.810 in H2O (201.8 Pa)
Bearing Type : Ball
Fan Type : Motorized Impellers
Features : Permanent Split Capacitor Motor, Speed Sensor (Tach)
Noise : 61.0 dB(A)
Power (Watts) : 80.0W
RPM : 3000 RPM
Termination : 5 Terminals
Ingress Protection : -
Operating Temperature : -4 ~ 158°F (-20 ~ 70°C)
Approvals : CE, cUL, TUV, UL
Weight : 3 lbs (1.4kg)
0
13 in stock
