Tamura Corporation of America
- Established in 1951, Microtran Corporation manufactured high-quality, magnetic components for both commercial and military applications. Offshore facilities provided expanded manufacturing capabilities on an extremely cost-effective basis for large volume requirements. Modified catalog items and custom designs were available on special order to meet customers' exact requirements.
Tamura Corporation of America acquired Microtran's product line and customer base in 1994. Prior to this acquisition, Tamura had been a subcontractor for Microtran for at least ten years and had manufactured many of the products found in the Microtran catalog. Since the acquisition, Tamura has combined identical and similar products into one product bearing a dual marking of both the Tamura and Microtran part numbers. This "dual marking" has enabled Tamura to continue to supply customers whose drawings referenced only the Microtran part number.
Part Number
Manufacturer
Description
Unit Price
In Stock
Tamura
Manufacturer : Tamura
Series : 3FD-3xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 6.3V, Series 12.6V
Current - Output (Max) : Parallel 400mA, Series 200mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 2.4 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 35.56mm L x 31.00mm W
Height - Seated (Max) : 32.10mm
Voltage - Isolation : 2500Vrms
Weight : -
0
2413 in stock
Tamura
Manufacturer : Tamura
Series : 3FD-3xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 8V, Series 16V
Current - Output (Max) : Parallel 300mA, Series 150mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 2.4 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 35.56mm L x 31.00mm W
Height - Seated (Max) : 32.10mm
Voltage - Isolation : 2500Vrms
Weight : -
0
29723 in stock
Tamura
Manufacturer : Tamura
Series : 3FD-3xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 10V, Series 20V
Current - Output (Max) : Parallel 240mA, Series 120mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 2.4 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 35.56mm L x 31.00mm W
Height - Seated (Max) : 32.10mm
Voltage - Isolation : 2500Vrms
Weight : -
0
19561 in stock
Tamura
Manufacturer : Tamura
Series : 3FD-3xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 12V, Series 24V
Current - Output (Max) : Parallel 200mA, Series 100mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 2.4 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 35.56mm L x 31.00mm W
Height - Seated (Max) : 32.10mm
Voltage - Isolation : 2500Vrms
Weight : -
0
788 in stock
Tamura
Manufacturer : Tamura
Series : 3FD-3xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 14V, Series 28V
Current - Output (Max) : Parallel 170mA, Series 85mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 2.4 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 35.56mm L x 31.00mm W
Height - Seated (Max) : 32.10mm
Voltage - Isolation : 2500Vrms
Weight : -
0
2988 in stock
Tamura
Manufacturer : Tamura
Series : 3FD-3xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 18V, Series 36V
Current - Output (Max) : Parallel 130mA, Series 65mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 2.4 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 35.56mm L x 31.00mm W
Height - Seated (Max) : 32.10mm
Voltage - Isolation : 2500Vrms
Weight : -
0
129 in stock
Tamura
Manufacturer : Tamura
Series : 3FD-3xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 24V, Series 48V
Current - Output (Max) : Parallel 100mA, Series 50mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 2.4 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 35.56mm L x 31.00mm W
Height - Seated (Max) : 32.10mm
Voltage - Isolation : 2500Vrms
Weight : -
0
24 in stock
Tamura
Manufacturer : Tamura
Series : 3FD-3xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 28V, Series 56V
Current - Output (Max) : Parallel 90mA, Series 45mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 2.4 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 35.56mm L x 31.00mm W
Height - Seated (Max) : 32.10mm
Voltage - Isolation : 2500Vrms
Weight : -
0
272 in stock
Tamura
Manufacturer : Tamura
Series : 3FD-4xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 5V, Series 10V
Current - Output (Max) : Parallel 1.2A, Series 600mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 6 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 41.50mm L x 34.83mm W
Height - Seated (Max) : 34.55mm
Voltage - Isolation : 2500Vrms
Weight : -
0
233 in stock
Tamura
Manufacturer : Tamura
Series : 3FD-4xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 6.3V, Series 12.6V
Current - Output (Max) : Parallel 1A, Series 500mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 6 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 41.50mm L x 34.83mm W
Height - Seated (Max) : 38.00mm
Voltage - Isolation : 2500Vrms
Weight : -
0
1401 in stock
Tamura
Manufacturer : Tamura
Series : 3FD-4xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 8V, Series 16V
Current - Output (Max) : Parallel 800mA, Series 400mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 6 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 41.50mm L x 34.83mm W
Height - Seated (Max) : 38.00mm
Voltage - Isolation : 2500Vrms
Weight : -
0
753 in stock
Tamura
Manufacturer : Tamura
Series : 3FD-4xx
Part Status : Active
Type : Laminated Core
Voltage - Primary : 115V, 230V
Voltage - Secondary (Full Load) : Parallel 10V, Series 20V
Current - Output (Max) : Parallel 600mA, Series 300mA
Primary Winding(s) : Dual
Secondary Winding(s) : Dual
Center Tap : No
Power - Max : 6 VA
Mounting Type : Through Hole
Termination Style : PC Pin
Size / Dimension : 41.50mm L x 34.83mm W
Height - Seated (Max) : 34.55mm
Voltage - Isolation : 2500Vrms
Weight : -
0
1119 in stock
